PST-600-24 - Samlex America Samlex PST Series 600W 24V Pure Sine Wave Inverter

Samlex PST Series 600W Pure Sine Wave Inverter - 24V

This high-efficiency inverter converts 24 Volts DC to 600 Watts of pure sine-wave AC power at 120 Volts, 60 Hz. It is ideal for various applications including service vehicles, mobile offices, boats, and emergency backup power.

Features include a built-in electronic GFCI, overload protection, low battery alarm/shut down, and a low idle power draw of less than 0.5 Amps. The inverter provides AC power through a NEMA-20R GFCI duplex outlet on the front panel.

Main Features:

• High efficiency for reliable power conversion
• Temperature controlled cooling fan reduces energy consumption
• Wide operating DC input range: 21.4 - 33.0 VDC
• Commercial-grade design for heavy-duty loads and continuous operation
• Universal Protection Circuit: low voltage, over voltage, over temperature, over load & short circuit protections
• Low idle power draw
• Dual GFCI protected AC outlets
• Optional remote control available (Model RC-15A, sold separately)
• Includes pin-type battery cable lugs
• Safety certified to ETL and UL standards

Specifications:

• Input: 24 VDC
• Output: 120 VAC
• Watts: 600 Watts
• Surge: 1000 Watts
• Weight: 5.9 lbs (2.7 kg)
• Dimensions: 9.37 x 10.87 x 3.23 in (238 x 276.2 x 82 mm)
• Warranty: 2 Year Limited

Applications:

• Service vehicles
• Mobile Offices
• Boats
• Recreation Vehicles, Camping
• Telecommunication
• Field work / Construction sites
• Solar power systems
• Emergency backup power
• Home electronics: TV, VCR, video games
• Computers, printers

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

The Samlex PST Series 600W Pure Sine Wave Inverter converts 24 Volts DC to 600 Watts of pure sine-wave AC power at 120 Volts, 60 Hz. This unit is designed for applications requiring stable and clean power, such as service vehicles, mobile offices, boats, and emergency backup systems. It provides AC power through a NEMA-20R GFCI duplex outlet on the front panel.

Key features include a wide operating DC input range of 21.4 - 33.0 VDC and a low idle power draw of less than 0.5 Amps, which helps conserve battery life. The inverter incorporates a Universal Protection Circuit for low voltage, over voltage, over temperature, overload, and short circuit conditions, enhancing operational safety and reliability. A temperature-controlled cooling fan manages heat, and the commercial-grade design supports heavy-duty loads and continuous operation. The PST-600-24 includes pin-type battery cable lugs and is safety certified to ETL and UL standards.
