Product Overview
General InformationThe new standard in precise color coverage. Expect vivid, accurate color precision, ultrathin bezels and wide color coverage to suit your professional needs with the Dell UltraSharp 27 Monitor with PremierColor. Ideal color coverage: The new UP2716D Monitor with PremierColor offers wide coverage of industry color standards with four color spaces, plus user-enabled color customization. You'll also enjoy exceptional color accuracy and consistency right out of the box with an extremely precise Delta-E Outstanding view: Experience seamless dual or multi-monitor setup with ultrathin bezels. You can count on beautiful clarity with QHD resolution, plus consistent color across and ultrawide viewing angles. Unrivalled reliability: Get complete peace of mind with Dell's Premium Panel Guarantee and Advanced Exchange Service. Technical InformationNumber of Screens: 1Screen Size Class: 27"Viewable Screen Size: 27"Screen Mode: WQHDScreen Surface: Anti-glarePanel Technology: In-plane Switching (IPS) TechnologyResponse Time: 6 msAspect Ratio: 16: 9Horizontal Viewing Angle: 178Vertical Viewing Angle: 178Adjustable Display Angle: YesAdjustable Display Height: YesAdjustable Display Pivot: YesBacklight Technology: LEDTilt Angle: -5to21Features: Mobile High-Definition Link (MHL)Features: Security LockFeatures: PremierColor TechnologyHorizontal Frequency: 88 kHzAdjustable Stand Height: YesVideoMaximum Resolution: 2560 x 1440Standard Refresh Rate: 60 HzColor Supported: 1.07 Billion ColorsContrast Ratio: 2,000,000: 1Brightness: 300 NitInterfaces/PortsHDMI: YesUSB: YesUSB Standard: USB 3.0DisplayPort: YesBuilt-in DevicesBuilt-in Devices: USB HubPower DescriptionInput Voltage: 120 V ACInput Voltage: 230 V ACOperating Power Consumption: 45 WPhysical CharacteristicsVESA Mount Compatible: YesVESA Mount Standard: 100 x 100Color: BlackHeight: 14.3"Width: 24.1"Depth: 2"Height with Stand: 21.27"Width with Stand: 24.07"Depth with Stand: 7.89"Weight (Approximate): 10.05 lbMiscellaneousPackage Contents: UltraSharp UP2716D Widescreen LCD Monitor Stand Power Cable mDP-DP Cable USB 3.0 Upstream Cable Divers and Documentation Media (CD) Quick Setup Guide Safety and Regulatory Information Factory Calibration Report Platform Supported: PCPlatform Supported: MacEnergy Star: YesEnvironmentally Friendly: YesEnvironmental Certification: ENERGY STAREnvironmental Certification: EPEAT GoldWarrantyLimited Warranty: 3 Year
Technical Specifications
Display
Color:
Black
Diagonally Viewable Size:
27 inch
Aspect Ratio:
Widescreen (16:9)
Panel Type, Surface:
In-Plane Switching
Optimal Resolution:
2560 x 1440 60Hz
Preset Display Area (H x V)
200301.75 sq-mm (310.47 sq-inches)
Contrast Ratio:
1000 to 1 (typical), 2000 to 1 (DCR)
Brightness:
300 cd/m2 (typical)
Response Time:
6ms fast mode GTG
Viewing Angle:
178o vertical / 178o horizontal
Adjustability:
Tilt, Swivel, Pivot, Height Adjust
Color Support:
1.07 billion colors
Pixel Pitch:
0.2331 mm x 0.2331 mm
Backlight Technology:
LED light bar system
Display Type:
Widescreen Panel Display
Display Screen Coating:
Anti-Glare with 3H hardness
Audio Output:
Yes
Features
Security:
Security lock slot (cable lock sold separately)
Flat Panel Mount Interface:
VESA (100 mm)
Built-in Devices:
N.A.
Connectivity
DisplayPort
Mini DisplayPort
2 x HDMI (MHL)
4 x USB3 with one charging port
2 x USB3 upstream
Electrical
Voltage Required:
100-240 VAC / 50 or 60 Hz 3 Hz / 1.6 A (maximum)
Power Consumption (Operational):
45 W (typical),40 W (Energy Star)
Power Consumption Stand by / Sleep:
Less than 0.3W
Environmental
Temperature Range Operating:
0 oC to 35oC (32 oF to 95 oF)
Temperature Range Non-operating:
Storage: -20 oC to 60 oC (-4 oF to 140 oF)
Shipping: -20 oC to 60 oC (-4 oF to 140 oF)
Humidity Range Operating:
10% to 80% (non-condensing)
Humidity Range Non-operating:
Storage: 5% to 90% (non-condensing)
Shipping: 5% to 90% (non-condensing)
Altitude Operating:
5,000 m (16,404 ft) (maximum)
Altitude Non-operating:
12,192 m (40,000 ft) (maximum)
Compliance and Standards
ENERGY STAR
EPEAT Gold
TCO
Product Safety, EMC and Environmental Datasheets Dell Regulatory Compliance Home Page Dell and the Environment
Whats in the box
Monitor
stand
Power Cable (varies by country)
mDisplayPort-DisplayPort Cable
USB 3.0 Upstream Cable
Divers and Documentation Media (CD)
Quick Setup Guide
Safety and Regulatory Information
Factory Calibration Report
Service / Support Details
Premium Panel Guarantee 3-Year Advanced Exchange Service
Item Dimension
8 x 25 x 22 Weight
27 DW
Warranty Information
3 Years
