TDE18-250FIM-100 - Pacer Group Pacer Fully-Insulated Male Disconnect Terminal - Red - 100 Pk

Pacer Fully-Insulated Male Disconnect Terminal - Red - 100 Pack

Creating a solid connection is crucial in every electrical system. Pacer's heat-shrink fully insulated disconnect terminals allow for easy disconnection and reconnection, simplifying maintenance tasks. These terminals are designed to withstand challenging environments with superior moisture protection, ensuring reliability.

The built-in heat-activated adhesive liner provides an environmentally sealed connection for wires ranging from 22 AWG to 10 AWG, safeguarding against water, oil, gas, and corrosion. The robust design also protects connectors from physical abuse and abrasion. Easy disconnection makes equipment removal or field service maintenance hassle-free.

The insulation color indicates suitable wire gauge: Red for 22-18 AWG, Blue for 16-14 AWG, and Yellow for 12-10 AWG. Choose the right heat shrink fully insulated disconnect terminal by consulting a Pacer expert if needed.

Features:

• Protects connections from moisture, salt spray, and corrosion
• Enhances vibration resistance in harsh environments
• Offers strain relief for added durability

Characteristics:

• Shrink Ratio: Approx. 3:1 at 135 �C
• Operating Temperature: -55 �C to 125 �C
• Volume Resistivity: 10^15 Ohm-cm�
• Dielectric Strength: 900-V/mil
• Voltage Rating: 600-V

Specifications:

• AWG: 22-18
• Disconnect/Bullet Size: 0.250 in.
• Insulation Color: Red
• Package Size: 100

Compliances:

• UL
• CSA
• RoHS

The Pacer Fully-Insulated Male Disconnect Terminal, part number TDE18-250FIM-100, is a component for electrical systems requiring robust, re-connectable terminations. This product is designed for IT and industrial environments where reliable connections are critical and maintenance tasks benefit from easy disconnection. It addresses common issues such as moisture ingress, corrosion, and physical abrasion that can compromise electrical integrity.

These terminals feature a heat-shrink, fully insulated design with a heat-activated adhesive liner, creating an environmentally sealed connection. This sealing protects against water, oil, gas, and corrosion, making them suitable for challenging conditions. The red insulation indicates compatibility with 22-18 AWG wires. Key characteristics include a 3:1 shrink ratio, an operating temperature range of -55 �C to 125 �C, and a 600-V voltage rating. The 0.250-inch disconnect size facilitates straightforward equipment removal or field service, enhancing operational efficiency.
