Technical Specifications
General
Display Type
LED-backlit LCD monitor / TFT active matrix
Energy Class
Class C
Diagonal Size
23.8"
Viewable Size
23.8"
Built-in Devices
USB 3.0 hub
Panel Type
IPS
Aspect Ratio
16:9
Native Resolution
4K UHD (2160p) 3840 x 2160 (DisplayPort: 60 Hz, HDMI: 30 Hz)
Pixel Pitch
0.13725 mm
Brightness
300 cd/m2
Contrast Ratio
1000:1 / 2000000:1 (dynamic)
Color Support
1.07 billion colors
Response Time
8 ms (typical)
6 ms (gray-to-gray)
Vertical Refresh Rate
29 - 76 Hz
Horizontal Refresh Rate
31 - 140 kHz
Video Bandwidth
533.25 MHz
Horizontal Viewing Angle
178
Vertical Viewing Angle
178
Screen Coating
Anti-glare, 3H Hard Coating
Backlight Technology
LED backlight
Controls and Adjustments
Brightness, contrast, sharpness, rotation, input select, color temperature, uniformity, aspect control
OSD Languages
Chinese (simplified), Brazilian Portuguese, English, German, French, Russian, Spanish, Japanese
Features
LED edgelight system, stand lock, 99% sRGB color gamut, Multi-Stream transport (MST), Energy Gauge, Energy Saver, Mercury free, Transition Minimized Differential Signaling (TMDS) technology, 82.09% (CIE 1931) color gamut, 102.28% (CIE 1976) color gamut, arsenic-free glass, Factory Calibration Report
Color
Black
Bundled with
3-Years Advanced Exchange Service and Premium Panel Guarantee
Connectivity
Interfaces
4 x USB 3.0 downstream (Type A)
USB 3.0 upstream (Type B)
MHL / HDMI
DisplayPort
Mini DisplayPort
DisplayPort output (MST)
Audio line-out (mini-jack)
Mechanical
Display Position Adjustments
Height, pivot (rotation), swivel, tilt
Tilt Angle
-5/+21
Rotation Angle
90
Height Adjustment
5.1 in
Flat Panel Mount Interface
100 x 100 mm
Miscellaneous
Features
Security lock slot (cable lock sold separately), LED indicator, integrated cable management, portrait / landscape mode, VESA interface support, Dell Soundbar mounting slots
Included Accessories
Stand, cable management cover
Cables Included
1 x Mini DisplayPort-DisplayPort cable - miniDisplayPort to DisplayPort - 6 ft
1 x SuperSpeed USB cable - USB Type A to B - 6 ft
Mounting Kit
Optional
Compliant Standards
Plug and Play, VESA EDID, DDC/CI, TCO Displays
Security Slot Type
Kensington security slot
Power
Voltage Required
AC 120/230 V (50/60 Hz)
Power Consumption Operational
90 Watt
Power Consumption Stand by
0.5 Watt
Power Consumption Sleep
0.5 Watt
Software / System Requirements
Included Software
Drivers and Utilities, Dell Display Manager
Environmental Standards
ENERGY STAR Certified
Yes
Environmental Parameters
Min Operating Temperature
32oF
Max Operating Temperature
95oF
Humidity Range Operating
10 - 80% (non-condensing)
Compatibility Information
Designed For
Dell OptiPlex 3040
Item Dimension (L"xW"xH")
27 x 10 x 18
Weight
35.00 LB
Warranty Information
3 yr Advance Exchange and Limited Hardware Warranty
