Technical Specifications
Physical
Various selection of port counts, with or without PoE and fiber support
Fanless design for silent operation (non-PoE models only)
Green Technology
Link Status detection
IEEE 802.3az compliant
Time-based PoE
Number of 10/100/1000BASE-TX ports
24 ports
Number of combo ports
2 ports
PoE Supported Models
802.3af/802.3at/24 ports/370W
Switch Capacity
52 Gbps
Maximum Forwarding Rate
38.69 Mpps
MAC Address Table Size
16K
Packet Buffer
1.5 Mbits
Flash Memory
16 Mbytes
Power
Yes
Link/Activity/Speed
Yes
Power Consumption (Maximum)
387W (PoE on)
Power Input
100 to 240 VAC, 50 to 60Hz internal universal power supply
Ventilation
2 fans
Heat Dissipation
1470.46 BTU per hour
MTBF
269,291 hours
Item Dimension (L"xW"xH")
20 x 17 x 4
Weight
9 lb
Warranty Information
Limited Lifetime
