Product Overview
The D-Link DXS-1210-12SC 10 Gigabit Ethernet SmartPro Switch is a cost-effective 10 Gigabit switch capable of servicing a range of network needs in any business. Supporting 10GBase-T/SFP+ combo ports, this switch provides connection flexibility across a network allowing easier network integration. With high performance and low latency, the DXS-1210-12SC fulfills the needs for virtualization, cloud services, and server-to-server applications, making it perfect for Small-to-Medium-Business (SMB) customers.
Technical Specifications
Interfaces
DXS-1210-12SC:
10 10G SFP+ ports
2 10GBASE-T/SFP+ combo ports Port Standard and Functions
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3az compliance
IEEE 802.3an 10GBASE-T 10GbE over copper
IEEE 802.3ae 10GbE over fiber
IEEE 802.3z 1000BASE-X
Auto MDI/MDIX support for 1000/10GBASE-T Network Cables for 10GBASE-T
CAT-6 (30m max)
CAT-6A or CAT-7(100m max)
Media Interface Exchange
Auto MDI/MDIX adjustment for all twisted-pair ports Performance
Switching Capacity :
DXS-1210-12SC: 240 Gbps
Maximum Packet Forwarding Rate
DXS-1210-12SC: 178.56 Mpps
Transmission Method : Store-and-forward
MAC Address Table : Up to 16,000 entries per device Physical/Environmental
AC Input
100 to 240 VAC
Maximum Power Consumption
DXS-1210-12SC: 43.81 watts
Standby Power Consumption
DXS-1210-12SC: 25.22 watts Diagnostic LEDs :
Link/Activity/Speed (Per 10GBASE-T port)
Link/Activity/Speed (Per 10G SFP+ port)
Power/Fan (Per device) Certifications
CE
FCC
C-Ticket
VCCI
BSMI
CCC Safety
cUL
CB
CE
CCC
BSMI Item Dimension (L"xW"xH"):
17.36 x 8.26 x 1.73
Weight:
6.01 lb
Warranty Information:
Limited Lifetime
