Technical Specifications
Enclosure Color
Black Touch Technology and Capacity
SAW (IntelliTouch Surface Acoustic Wave) - Single Touch Touch Interface
Dual serial/USB 2.0 Diagonal Size
12.1" diagonal, Active matrix TFT LCD (LED) On Screen Display
Accessible through switches on the units tethered OSD Control box.
Controls: Menu, Up, Down, Select, Power
Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Sharpness, Color Temperature, OSD Timeout, OSD Language, OSD H-Position, OSD V-Position, Recall Defaults, Video Priority, Information, Touch On Sleep Mode, Touch Through
Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese
Lockouts: OSD, Power
Aspect Ratio
4:3 Active Area (mm)
9.69" x 7.26"/ 246mm x 184.50mm Resolution
800 x 600 at 60 Hz Other Supported Resolutions
640 x 480 60Hz
800 x 500, 60Hz
800 x 600 60Hz
Viewing Angle
Horizontal: +/-89o or 178o total / Vertical: +/-89o or 178o total Number of Colors
16.2 million Brightness (typical)
405 nits Response Time-total (typical)
25 msec Contrast Ratio
1500:1 Input Video Format
HDMI V1.3 Type A receptacle for HDMI input
Analog VGA on Female DB-15 connector
DisplayPort V1.1a - Supports later versions of Display Port video input
Input Video Frequency
Horizontal: 30 - 38 KHz
Vertical: 50 - 75 Hz
Video Interface
HDMI, VGA and Display Port Power Supply
External DC - Optional power brick (sold separately) Input power connector (Monitor)
Coaxial power jack (2.0mm (+0.0 -0.1mm) pin outer diameter, 6.4mm (+/- 0.3mm) barrel inner diameter, 8.8mm (+/- 0.3mm) barrel depth) Input Voltage
12VDC +/- 5%
