Technical Specifications
Enclosure Color
Black
Touch Technology and Capacity
PCAP (TouchPro Projected Capacitive) - 10 Touch
Touch Interface
USB 2.0
Diagonal Size
10.1" diagonal, Active matrix TFT LCD (LED)
On Screen Display
Accessible through switches on the units tethered OSD Control box.
Controls: Menu, Up, Down, Select, Power
Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, OSD H-Position, OSD V-Position, Recall Defaults, Video Priority, Information, Touch On Sleep Mode, Touch Through
Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese
Lockouts: OSD, Power
Aspect Ratio
16:10
Active Area (mm)
8.54" x 5.34"/ 216.96mm x 135.6mm
Resolution
1280 x 800 at 60Hz
Other Supported Resolutions
640 x 480 60Hz
720 x 400 70Hz
800 x 500 60Hz
800 x 600 56, 60Hz
1024 x 768 60Hz
1280 x 800 60Hz
Viewing Angle
Horizontal: +/-85o or 170o total / Vertical: +/-85o or 170o total
Number of Colors
262,000
Brightness (typical)
LCD panel: 350 nits
TouchPro PCAP: 315 nits
Response Time-total (typical)
25 msec
Contrast Ratio
800:1
Input Video Format
HDMI V1.3 Type A receptacle for HDMI input
Analog VGA on Female DB-15 connector
DisplayPort V1.1a - Supports later versions of Display Port video input
Input Video Frequency
Horizontal: 30 - 60 KHz
Vertical: 50 - 75 Hz
Video Interface
HDMI, VGA and Display Port
Power Supply
External DC - Optional power brick (sold separately)
Input power connector (Monitor)
Coaxial power jack (2.0mm (+0.0 -0.1mm) pin outer diameter, 6.4mm (+/- 0.3mm) barrel inner diameter, 8.8mm (+/- 0.3mm) barrel depth)
Input Voltage
12VDC +/- 5%
