Technical Specifications
Interface
Ethernet:
2 10/100/1000 Mbps WAN Ports
4 10/100/1000 Mbps LAN Ports
USB:1 USB 2.0
Console:1 RJ-45 System Performance3
Firewall Throughput2:70Mbps
VPN Throughput4:35Mbps
Concurrent Sessions:30,000
New Sessions (per second) 300 600:300
Policies:
100 (Each Feature)
200 (Firewall Rule) Internet Connection Type
Static / Dynamic IP:Yes
PPPoE/ L2TP/ PPTP:Yes
Multiple PPPoE:Yes Firewall System
Static Route:Yes
Dynamic Route:RIPv1, RIP v2, OSPF1
Inter-VLAN Route:Yes
Dynamic DNS:Yes
NAT, PAT:Yes
Web Content Filtering:Static URL, Keywords
Intrusion Prevention System (IPS) :Signature package included in Firmware Networking
DHCP Server/ Client:Yes
DHCP Relay:Yes
IEEE 802.1q VLAN:Yes
VLAN:Port Based
IP Multicast:IGMP Proxy
IPv6:Yes
Route Failover:Yes
Outbound Load Balancing:Yes Virtual Private Network (VPN)
VPN Tunnels:35
Encryption Methods:DES, 3DES, AES, Twofish, Blowfish, CAST-128, NULL
IPSec/PPTP/L2TP Server:Yes
IPSec NAT Traversal:Yes
Dead Peer Detection:Yes
IP Encapsulating Security Payload (ESP) :Yes
IP Authentication Header (AH) :Yes
VPN Tunnel Keep Alive:Yes
Hub and Spoke:Yes SSL Virtual Private Network (SSL VPN)
SSL VPN Tunnels:10
Bandwidth Management
Max. Bandwidth Control:Yes
Priority Bandwidth Control:Port-Based QoS (3 Classes) System Management
Web-based User Interface:HTTP, HTTPS
Command Line:Yes
SNMP:v1, v2c, v3
Physical
Power Supply:Internal Power Supply Unit DC12V/2.5A
EMI:FCC Class B, CE Class B, VCCI, C-Tick, IC
Safety:cUL, LVD (EN60950-1)
MTBF:260,000 hours Item Dimension (L"xW"xH"):
15.59 x 10.75 x 3.15
Weight:
3.75 lb
Warranty Information:
Limited Lifetime
