Technical Specifications
PORTS:
PoE and Data
Label: PoE IN
IEEE 802.3 / 10BASE-T
IEEE 802.3u / 100BASE-Tx
IEEE 802.3ab / 1000BASE-T
IEEE 802.3af / 802.3at
Half/full-Duplex operation
CSMA/CD Data
Label: LAN OUT
IEEE 802.3 / 10BASE-T
IEEE 802.3u / 100BASE-Tx
IEEE 802.3ab / 1000BASE-T
Half/full-Duplex operation
CSMA/CD
PHYSICAL and ENVIRONMENTAL:
Temperature
Operating: 32 F to 122 F / 0 to 50 C
Storage: -22 F to 158 F / -30 C to 70 C Humidity
Operating: 5% to 95% RH
Storage 5% to 95% RH Power Consumption
Maximum: 32.4 Watts LED Indicators
Blue: Power On
Green: Link On DC POWER OUT:
Switchable Output Voltage
5V DC, 2.5A max
9V DC, 2A max
12V DC, 2A max 100 - 240V, 50/60 Hz Included Power Adapter Cables
5.5mm Male to 5.5mm Male
5.5mm Male to 3.8mm Male PoE FEATURES:
Standards
IEEE 802.3af, IEEE 802.3at Emissions (EMI) and Safety Certifications
Certifications: CE, FCC, VCCI, RCM, RoHS Item Dimension (L"xW"xH")
5 x 3 x 1
Weight
1.00 lb
Warranty Information
1 Year Limited
