Technical Specifications
MAC Address Table Size - 1K Switch Fabric - 1.6 Gbps Forwarding Capacity Transmission Method - Store-and-forward Diagnostic LEDs - Per Unit Power - Per Port Activity/Link Packet Buffer Memory - On Chip 64Kbyte Buffer Memory Per Device Forwarding Rate - 10Mbps- 14,880pps/100Mbps- 148,810pps Address Aging Timer - Automatic Update Max Power Consumption - 3.35 Watts (Max) RJ-45 - 10BASE-T, 100BASE-TX Universal UTP Cable Recognition for Straight-Through or Crossover Cables (MDI/MDI-X) IEEE - 802.3 Ethernet, 802.3u Fast Ethernet, 802.3x Flow Control Emissions - FCC Class B, CE Class B, VCCI Class B Power Supply - DC 7.5V / 1A External Safety - CSA International Dimensions (W x H x D) - 7.5 x 4.5 x 1.25 inches (192.5 x 118.5 x 32 mm) Warranty - 5 years
