Technical Specifications
Device Interfaces
16 10/100 Mbps PoE ports
2 10/100/1000BASE-T/SFP combo ports
Standards
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3z
IEEE 802.3x Flow Control
IEEE 802.3az Energy-Efficient Ethernet (EEE) Switching Fabric
7.2 Gbps
64 Byte Max. Forwarding Rate
5.36 Mpps
Transmission Method
Store-and-forward
MAC Address Table
8k Packet Buffer
384 Kbytes
Media Interface Exchange
Auto MDI/MDIX adjustment for all ports
LED Indicators
Per unit: Power
Per port: Activity / Link and Speed
Per PoE port: Power fail, Power OK Fan
1 Smart fan
PoE Standard
IEEE 802.3af
PoE Ports
Ports 116 up to 15.4 W per port
PoE Power Budget
246.4 watts Surge Protection
Ports 116 up to 2 kV
Power
Internal AC input: 100 240 VAC, 5060 Hz
Power Consumption
Maximum Power Consumption: 301.6 watts (PoE on), 15.6 watts (PoE off)
Standby Power Consumption: 9.3 W/100 V, 10.5 W/240 V MTBF
361,802 hours
Heat Dissipation
1029.5 BTU/h
Certifications
FCC Class A
CE
CCC
RoHS
VCCI
BSMI
C-Tick Safety
CB
cUL
LVD
CCC
BSMI Item Dimension (L"xW"xH"):
14.25 x 13.15 x 4.09
Weight:
4.62 lb
Warranty Information:
Limited Lifetime
