Technical Specifications
Output
Nominal Output Voltage
120V, 208V
Maximum Total Current Draw Per Phase: 24A
Output Connections: (7) IEC 320 C13, (1) IEC 320 C19, (16) NEMA 5-20R
Overload Protection: Yes Input
Nominal Input Voltage: 120V, 208V
Input Frequency: 50/60 Hz
Regulatory Derated Input Current (North America): 24A
Input Connections: NEMA L14-30P
Cord Length: 3.05 Meters
Number of Power Cords: 1
Maximum Input Current Per Phase: 30A
Load Capacity: 5760 VA Color
Black Environmental
Operating Environment: -5 to -45 C
Operating Relative Humidity: 5 to 95%
Operating Elevation: 0 to 3000 Meters
Storage Temperature: -25 to 65 C
Storage Relative Humidity: 5 to 95%
Storage Elevation: 0 to 15000 Meters Conformance
Regulatory Approvals: cUL Listed, FCC Part 15 Class A, ICES-003, UL 60950-1, UL Listed Sustainable Offer Status
RoHS: Compliant
REACH: REACH, Contains No SVHCs
Battery Directive: Compliant
Battery Notes: Contains Lithium Coin Cell
Other Environmental Compliance: China RoHS Package Contents
Installation Guide
Rack Mounting Brackets
Safety Guide
Serial Configuration Cable Item Dimension (L"xW"xH")
4.69 x 80.35 x 6.48
Weight
22.48 lb
Warranty Information
2 Years Repair and Replace
