Product Overview
AST (EXTREME BLACK ENABLED), 1.6X ZOOM, H AND V LENS SHIFT,
Technical Specifications
TECHNICAL SPECIFICATIONS
360 Operation
Yes Aspect Ratio
16:10 (native), 16:9 and 4:3 compatible Audio
2 x 10W speakers (stereo) Brightness
5,000 ANSI lumens Color Wheel
4 Segment RYGB Compatible Aspect Ratio
16:9 (native) and 4:3 (compatible) Connections
2x HDMI, VGA, HDBaseT, mic in, audio in, VGA out, audio out, 3D sync, 12V trigger, RS-232C, wired remote, USB type A, mini USB, IR receiver, RJ45 Contrast Ratio
300,000:1 (ExtremeBlack enabled) 1,800:1 full on/full Off Display Technology
Single DMD, 0.65" 1080P DMD, DC3 DLP Technology by Texas Instruments Displayable Colors
1.07 billion Keystone Correction
+/-30o vertical and horizontal Light Source Type
Laser phosphor Light Source Life
Up to 20,000 hours Lens Shift
Vertical +20% -10% Horizontal +/-10% Maximum Resolution
WUXGA (1920x1200) Native Resolution
WXGA (1280 x 800) Noise Level
28dB (Eco) Operating Temperature
Operating temperature at sea level up to 10,000 feet is equal to 104o F (max). Must manually switch to high altitude mode from 5,000 feet and above to maintain optimal functionality Portrait Mode
Yes
