Technical Specifications
CUDA Cores
2560
Peak Single Precision FP32 Performance
8.9 TFLOPS
Multi-GPU Scalability
NVIDIA SLI HB
GPU Memory
16 GB GDDR5
Memory Interface
256-bit
Memory Bandwidth
288 GB/s
System Interface
PCI Express 3.0 x16
Maximum Power Consumption
180 W
Energy Star Enabling
Yes
Thermal Solution
Ultra-quiet active fansink
Form Factor
4.40 H x 10.50 L, Single Slot
Display Connectors
DP 1.4 (4) + DVI-D DL + Stereo
DisplayPort with Audio
Yes
DVI-D Single-Link Connector
Via included adapter
HDMI Support
Via optional adapters
VGA Support
Via optional adapters
Number of Displays Supported
4
Maximum DP 1.4 Resolution
HDR 7680 x 4320 at 30Hz (30-bit color)
5K Display Support
HDR 5120 x 2880 at 60Hz (30-bit color)
4K Display Support
HDR 4096 x 2160 at 60Hz or 3840 x 2160 at 60Hz
Maximum DVI-D DL Resolution
2560 x 1600 at 60Hz via 3rd party adapter
Maximum DVI-D SL Resolution
1920 x 1200 at 60Hz via included adapter
HDCP Support
Yes
Professional 3D Support
Yes, via included stereo connector bracket
Quadro Sync II Compatible
Yes (Frame Lock and Genlock)
NVIDIA GPU Direct Compatible
Yes
Graphics APIs
Shader Model 5.1, OpenGL 4.5, DirectX 12.0, Vulkan 1.0
Compute APIs
CUDA, DirectCompute, OpenCL
NVIEW
Yes
NVIDIA MOSAIC
Yes (Windows 10, 8.1, 8, 7, and Linux)
Item Dimension (L inchxW inchxH inch)
14 x 8 x 4 Weight
4.01lb Warranty Information
3 Years
