Technical Specifications
TECHNICAL SPECIFICATIONS
Aspect Ratio
16:9 (native), 4:3 and LBX compatible Audio
2x 5 Watt Speakers Brightness
3,500 ANSI lumens Color Wheel
RGBWRGBW 8 segment Connections
2xHDMI 2.0 (w/ HDCP 2.2), VGA-in, audio-in (3.5mm), audio-out, S/PDIF out (optical), USB 2.0 (service), USB (for Alexa Wi-Fi adapter), USB (media), USB, RJ-45, RS-232C, 12V trigger Contrast Ratio
Up to 500,000:1 with Dynamic Black Display Technology
Single 0.47" 4K UHD DMD DLP by Texas InstrumentsTM Image Size
34.1" - 302.4" (34.1" to 140" optimal image size) Light Source Life
4,000/10,000/15,000 (Bright/ECO/Dynamic) Lens Shift
Vertical 15% offset (with tolerance +/- 5%) Maximum Resolution
4K (4096 x 2160) at 30Hz Native Resolution
4K UHD (3840 x 2160) at 60Hz with XPR Technology Noise Level
25dB Offset
100% (see Lens Shift) Operating Temperature
41-104oF (5-40oC), 85% max humidity Power Consumption
317W typical (Bright mode), 348W max (Bright mode), 259W typical (Eco+ mode), 285W max (Eco+ mode) Power Supply
AC input 100-240V, 50-60Hz, auto-switching Projection Distance
2.9 ft. - 34.89 ft. Projection Lens
F is equal to 2.5 - 3.26, F is equal to 20.91 - 32.62 mm manual focus Projection Method
Front, rear, ceiling mount, table top
