TDT06F-8RS - Pacer Group DT Deutsch Plug Repair Kit - 14 AWG, 8 Position

DT Deutsch Plug Repair Kit - 14 AWG, 8 Position

This DT Deutsch Plug Repair Kit is specifically designed for 14 AWG wires, utilizing larger size 16 contacts (Deutsch Pin P/N 0460-215-16141, Socket P/N 0462-209-16141). The DT series connectors are engineered for applications using 20-14 wire gauge, allowing electrical designers the flexibility to utilize multiple sizes of 16 contacts (20-14 AWG) each with a continuous capacity of 13 amps within a single shell. Pacer provides additional components for a wider range of applications.

Features:

• Complete pack includes all necessary components to assemble a connector
• Includes one to two extra terminals for convenience
• Cavity plugs provided to seal open circuits
• Ideal for wire-to-wire applications
• Field-proven reliability with rugged enclosed connectors

Compliances:

• Ingress Protection (IP) Level: IP68 and IP6K9K
• EU RoHS/ELV compliant
• UL-94 Recognized Standard

Characteristics:

• Wedge locks for ensuring contact alignment and retention
• Redundant silicone seals for enhanced durability
• Contacts are hand-insertable and removable for easy installation

Technical Specifications:

• Number of Cavities: 8
• Housing: Rectangular receptacle, plastic reinforced with glass fiber
• Contact Size: 16 (13 amp)
• Wire Size: 14 AWG
• Holds Pin/Socket: Sockets
• Operating Temperature: -55°C to 125°C

Contents:

• (1) 8 position plug
• (1) 8 position wedge lock
• (10) sockets
• (4) cavity plugs

The Pacer Group TDT06F-8RS DT Deutsch Plug Repair Kit is designed for IT and industrial applications requiring reliable wire-to-wire connections. This kit supports 14 AWG wires and utilizes size 16 contacts, each rated for a continuous capacity of 13 amps. It is suitable for environments where robust, sealed connections are necessary, offering IP68 and IP6K9K ingress protection. The kit includes an 8-position rectangular receptacle housing, an 8-position wedge lock, ten sockets, and four cavity plugs, providing all components needed for assembly. Features like redundant silicone seals and hand-insertable/removable contacts simplify installation and enhance durability. This repair kit addresses the need for field-proven, compliant connectivity in systems operating from -55�C to 125�C, ensuring contact alignment and retention through wedge locks.
