Technical Specifications
CPU
Onboard Intel Celeron 847/807 processors
Solid Capacitor for CPU side
CHIPSET
Intel NM70 Express Chipset GRAPHICS
Supports DirectX 10.1
Supports Full HD 1080P Blu-ray / HD-DVD Playback MEMORY
Dual-channel DDR3 Memory architecture
Supports DDR3 1333/1066 non-ECC, Un-buffered SDRAM Memory
2 X DDR3 SO-DIMM socket
Support up to 16 GB
The memory maximum size we have tested is 16 GB EXPANSION SLOT
1 X PCI Express X 1 slot(s) (optional)
2 X Mini PCI Express X1 slot(s)
Storage
Support by Intel NM70 Express Chipset
1 X Serial ATAIII 6Gb/s
2 X Serial ATAII 3Gb/s Audio
2-Channel HD audio CODEC
LAN
Realtek 8111E Gigabit Fast Ethernet Controller
Wake-On-LAN USB
Support by NM70 Express Chipset
4 X USB2.0 port(s) Up to 480 Mb/s
Back Panel 2 port(s)
Onboard 2 port(s) REAR PANEL I/O
2 x Audio jacks (Line Out, Mic In)
1 X RJ-45 port
1 X HDMI port(s)
1 X D-Sub (VGA) port(s)
4 X USB2.0 port(s)
1 X DC-in Connetor CONNECTORS and HEADERS
1 X 4-pin CPU_FAN connector
1 X 4-pin SYS_FAN connector with smart fan
1 X Front Panel switch/LED header
1 X Front panel audio header
1 X Speaker header
1 X USB 2.0 header Support additional 2 USB ports
1 X S/PDIF out header
1 X SATA III 6Gb/s connector(s)
2 X SATA II 3Gb/s connector(s)
1 X CLR_CMOS header
1 X IR header (optional)
1 X mSATA connector
1 X ME_UNLOCK header 1 X Chassis intrusion header
1 X Touch board header
1 X Camera header
1 X LVDS connector (optional)
1 X LDC header
1 X SATA power connector SYSTEM BIOS
AMI BIOS with 64 MB SPI Flash ROM
Supports M.I.B III Utility
ACPI DMI
F7 hot key for boot up devices option
Dual Display
Support ECS EZ BIOS Plug and Play, STR (S3) / STD (S4) , Hardware monitor, Multi Boot
Multi-Language BIOS
Audio, LAN, can be disabled in BIOS
Supports PgUp clear CMOS Hotkey
CPU FSB adjustment(increase of 1MHz) FORM FACTOR
Thin Mini ITX Form Factor
OS Support
Windows XP 32-bit
Windows XP 64-bit
Windows 7 32-bit
Windows 7 64-bit
Windows 8 32-bit
Windows 8 64-bit Certifications
CE/FCC Certification
ErP/EuP Certification
WHCK Certification Bundled Software
Free Bundle: Norton Internet Security ,CyberLink
PowerDVD, CyberLink PowerDirector 9, Muzee with trial version Item Dimension (L"xW"xH"):
9 x 8 x 2
Weight:
1.4 lb
Warranty nformation:
1 Year
