05-25420-17 - Broadcom LSI Logic Controller Card 05-25420-17 MegaRAID SAS 9361-8i 8-Port 2GB SATA/SAS PCI Express Retail

Lifecycle
Active RAID-on-Chip Controller
No RAID- Management Software
LSISAS3108 dual core RAID on Chip (ROC) MegaRAID Storage Manager,StorCLI (command-line interface),CTRL-R (BIOS configuration utility),HII (UEFI Human Interface Infrastructure) Cache Protection
Optional CacheVault Flash Module (LSICVM02)
Includes CVFM04, CVPM02, mounting clip, and cable
Physical Dimensions
MD2 Low Profile (6.6" x 2.536") Host Bus Type
x8 lane PCI Express 3.0 Cache Memory
1Gb 1866MHz DDR3 SDRAM Internal Ports
8 Data Transfer Rate
Up to 12Gb/s per port Devices Supported
Up to 240 SATA and/or SAS devices Internal Connectors
2 HD Mini-SAS SFF8643 (Horizontal mount) MTBF
1,343,187 Hours Operating Temperature
Maximum ambient: Controller Card: 55C, with optional CacheVault accessory (LSICVM02) 55CMaximum ambient: Controller Card: 60C (44.5C with LSIiBBU07 Operating Voltage
+12V, +3.3V OS
Extensive support includes Microsoft Windows Vista/2008/Server 2003/2000/XP, Linux, Solaris (x86), Netware, FreeBSD, VMware and more. Visit the downloads page for the most complete list of supported operating systems Regulatory Certifications
Australia/New Zealand (AS/NZS 3548), Canada (ICES-003), EMC: Class B-US (CFR 47, P15B), Europe (EN55022/EN55024), Japan (V-3/02.04), Safety: EN60950 Item Dimension (L"xW"xH")
6 x 11 x 2

Weight
1.00 lb

Warranty Information
3 Years
