CL(IDD) 22 cycles Row Cycle Time (tRCmin) 45.75ns(min.) Refresh to Active/Refresh Command Time (tRFCmin) 350ns(min.) Row Active Time (tRASmin) 32ns(min.) Maximum Operating Power IDD Specifications IDD Symbol 3200 Units IDD0 787 mA IDD0A 787 mA IDD1 893 mA IDD1A 919 mA IDD2N 714 mA IDD2NA 714 mA IDD2NT 759 mA IDD2NL 651 mA IDD2NG 714 mA IDD2ND 705 mA IDD2NP 714 mA IDD2P 478 mA IDD2Q 669 mA IDD3N 744 mA IDD3NA 744 mA IDD3P 512 mA IDD4R 1558 mA IDD4RA 1586 mA IDD4RB 1575 mA IDD4W 1544 mA IDD4WA 1592 mA IDD4WB 1487 mA IDD4WC 1537 mA IDD4WP 1752 mA IDD5B 2235 mA IDD5F2 1751 mA IDD5F4 1600 mA IDD6N 175 mA IDD6E 239 mA IDD6R 115 mA IDD6A 239 mA IDD7 1702 mA IDD8 92 mA IPP Symbol 3200 Units IPP0 36 mA IPP1 40 mA IPP2N 21 mA IPP2P 17 mA IPP3N 100 mA IPP3P 98 mA IPP4R 129 mA IPP4W 128 mA IPP5B 489 mA IPP5F2 324 mA IPP5F4 265 mA IPP6N 37 mA IPP6E 52 mA IPP6R 25 mA IPP6A 51 mA IPP7 142 mA IPP8 18 mA UL Rating 94 V - 0 Operating Temperature 0oC to +85oC Storage Temperature -55oC to +100oC Module Assembly DRAM: HYNIX (D-DIE) RCD: Rambus Item Dimension (L inchxW inchxH inch) 7 x 3 x 1 Weight 1.00lb Warranty Information Lifetime Warranty
