CL(IDD) 22 cycles Row Cycle Time (tRCmin) 45.75ns(min.) Refresh to Active/Refresh Command Time (tRFCmin) 350ns(min.) Row Active Time (tRASmin) 32ns(min.) Maximum Operating Power IDD Specifications IDD Symbol 3200 Units IDD0 1081 mA IDD0A 1081 mA IDD1 1241 mA IDD1A 1309 mA IDD2N 963 mA IDD2NA 964 mA IDD2NT 1053 mA IDD2NL 829 mA IDD2NG 959 mA IDD2ND 941 mA IDD2NP 973 mA IDD2P 627 mA IDD2Q 894 mA IDD3N 995 mA IDD3NA 994 mA IDD3P 696 mA IDD4R 2215 mA IDD4RA 2267 mA IDD4RB 2226 mA IDD4W 2236 mA IDD4WA 2330 mA IDD4WB 2054 mA IDD4WC 2239 mA IDD4WP 2608 mA IDD5B 3998 mA IDD5F2 3010 mA IDD5F4 2707 mA IDD6N 325 mA IDD6E 454 mA IDD6R 206 mA IDD6A 454 mA IDD7 4083 mA IDD8 159 mA IPP Symbol 3200 Units IPP0 71 mA IPP1 80 mA IPP2N 42 mA IPP2P 34 mA IPP3N 200 mA IPP3P 193 mA IPP4R 260 mA IPP4W 256 mA IPP5B 974 mA IPP5F2 646 mA IPP5F4 529 mA IPP6N 73 mA IPP6E 104 mA IPP6R 50 mA IPP6A 102 mA IPP7 521 mA IPP8 36 mA UL Rating 94 V - 0 Operating Temperature 0oC to +85oC Storage Temperature -55oC to +100oC Module Assembly DRAM: HYNIX (D-DIE) RCD: Rambus Item Dimension (L inchxW inchxH inch) 7 x 3 x 1 Weight 1.00lb Warranty Information Lifetime Warranty
