CL(IDD) 22 cycles Row Cycle Time (tRCmin) 45.75ns(min.) Refresh to Active/Refresh Command Time (tRFCmin) 350ns(min.) Row Active Time (tRASmin) 32ns(min.) Maximum Operating Power IDD Specifications IDD Symbol 3200 Units IDD0 1548 mA IDD0A 1549 mA IDD1 1708 mA IDD1A 1777 mA IDD2N 1431 mA IDD2NA 1431 mA IDD2NT 1609 mA IDD2NL 1161 mA IDD2NG 1422 mA IDD2ND 1385 mA IDD2NP 1450 mA IDD2P 925 mA IDD2Q 1296 mA IDD3N 1494 mA IDD3NA 1490 mA IDD3P 1062 mA IDD4R 2680 mA IDD4RA 2733 mA IDD4RB 2691 mA IDD4W 2702 mA IDD4WA 2797 mA IDD4WB 2520 mA IDD4WC 2704 mA IDD4WP 3074 mA IDD5B 4464 mA IDD5F2 3476 mA IDD5F4 3173 mA IDD6N 624 mA IDD6E 882 mA IDD6R 384 mA IDD6A 882 mA IDD7 4544 mA IDD8 290 mA IPP Symbol 3200 Units IPP0 112 mA IPP1 121 mA IPP2N 84 mA IPP2P 67 mA IPP3N 398 mA IPP3P 384 mA IPP4R 300 mA IPP4W 297 mA IPP5B 1014 mA IPP5F2 687 mA IPP5F4 570 mA IPP6N 146 mA IPP6E 207 mA IPP6R 99 mA IPP6A 204 mA IPP7 562 mA IPP8 70 mA UL Rating 94 V - 0 Operating Temperature 0oC to +85oC Storage Temperature -55oC to +100oC Module Assembly DRAM: HYNIX (D-DIE) RCD: Rambus Item Dimension (L inchxW inchxH inch) 7 x 3 x 1 Weight 1.00lb Warranty Information Lifetime Warranty
