CL(IDD) 21 cycles Row Cycle Time (tRCmin) 46.32ns(min.) Refresh to Active/Refresh Command Time (tRFCmin) 350ns(min.) Row Active Time (tRASmin) 32ns(min.) Maximum Operating Power IDD Specifications IDD Symbol 2933 Units IDD0 763 mA IDD0A 763 mA IDD1 869 mA IDD1A 890 mA IDD2N 679 mA IDD2NA 679 mA IDD2NT 724 mA IDD2NL 616 mA IDD2NG 679 mA IDD2ND 670 mA IDD2NP 679 mA IDD2P 452 mA IDD2Q 643 mA IDD3N 720 mA IDD3NA 720 mA IDD3P 485 mA IDD4R 1472 mA IDD4RA 1499 mA IDD4RB 1487 mA IDD4W 1470 mA IDD4WA 1501 mA IDD4WB 1409 mA IDD4WC 1452 mA IDD4WP 1636 mA IDD5B 2200 mA IDD5F2 1729 mA IDD5F4 1573 mA IDD6N 175 mA IDD6E 239 mA IDD6R 115 mA IDD6A 239 mA IDD7 1660 mA IDD8 92 mA IPP Symbol 2933 Units IPP0 36 mA IPP1 40 mA IPP2N 21 mA IPP2P 17 mA IPP3N 100 mA IPP3P 98 mA IPP4R 128 mA IPP4W 128 mA IPP5B 489 mA IPP5F2 324 mA IPP5F4 264 mA IPP6N 37 mA IPP6E 52 mA IPP6R 25 mA IPP6A 52 mA IPP7 140 mA IPP8 18 mA UL Rating 94 V - 0 Operating Temperature 0oC to +85oC Storage Temperature -55oC to +100oC Module Assembly DRAM: HYNIX (D-DIE) RCD: Rambus Item Dimension (L inchxW inchxH inch) 7 x 3 x 1 Weight 1.00lb Warranty Information Lifetime Warranty
