CL(IDD) 19 cycles Row Cycle Time (tRCmin) 46.25ns(min.) Refresh to Active/Refresh Command Time (tRFCmin) 350ns(min.) Row Active Time (tRASmin) 32ns(min.) Maximum Operating Power See IDD Table UL Rating 94 V - 0 Operating Temperature 0oC to +85oC Storage Temperature -55oC to +100oC IDD Specifications IDD Symbol 2933 IDD0 1493mA IDD0A 1493mA IDD1 1651mA IDD1A 1709mA IDD2N 1375mA IDD2NA 1376mA IDD2NT 1546mA IDD2NL 1109mA IDD2NG 1368mA IDD2ND 1340mA IDD2NP 1393mA IDD2P 870mA IDD2Q 1263mA IDD3N 1438mA IDD3NA 1438mA IDD3P 1005 mA IDD4R 2529mA IDD4RA 2579mA IDD4RB 2546mA IDD4W 2565mA IDD4WA 2635 mA IDD4WB 2381mA IDD4WC 2556 mA IDD4WP 2892mA IDD5B 4424mA IDD5F2 3425mA IDD5F4 3111 mA IDD6N 623mA IDD6E 882mA IDD6R 384 mA IDD6A 882 mA IDD7 4243 mA IDD8 290mA IPP Symbol 2933 IPP0 112 mA IPP1 121 mA IPP2N 84 mA IPP2P 67mA IPP3N 398 mA IPP3P 384 mA IPP4R 297mA IPP4W 293 mA IPP5B 1017 mA IPP5F2 687mA IPP5F4 567 mA IPP6N 146 mA IPP6E 207mA IPP6R 99 mA IPP6A 204 mA IPP7 521mA IPP8 70mA Item Dimension (L inchxW inchxH inch) 7 x 3 x 1
