Technical Specifications
1.JEDEC standard 1.35V and 1.5V
2.VDDQ 1.35V and 1.5V
3.1066MHz fCK for 2133Mb/sec/pin
4.8 independent internal bank
5.Programmable CAS Latency: 15, 14, 13, 12, 11, 10, 9, 8, 7, 6
6.Programmable Additive Latency: 0, CL - 2, or CL - 1 clock
7.8-bit pre-fetch
8.Bi-directional Differential Data Strobe
9.Internal(self) calibration : Internal self calibration through ZQ pin (RZQ : 240 ohm +/- 1%)
10.On Die Termination using ODT pin
11.Asynchronous Reset
12.PCB : Height 1.180 (30.00mm), double sided component CL(IDD)
11 cycles
Row Cycle Time (tRCmin)
44.22ns (min.)
Refresh to Active/Refresh Command Time (tRFCmin)
260ns (min.) Row Active Time (tRASmin)
31.875ns (min.)
Maximum Operating Power
TBD W 1.35V
UL Rating
94 V 0 Item Dimension (L"xW"xH"):
5.24 x 6.7 x 0.52
Weight:
0.5 lb
Warranty Information:
Lifetime Manufacture
