Product Overview
Interfaces/PortsHost Interface: PCI Express x1USB: NoNumber of Network (RJ-45) Ports: 1Network (RJ-45): YesSerial Port: NoTotal Number of Ports: 1Ethernet AUI: NoXJACK: NoPoE (RJ-45) Port: NoGeneral InformationProduct Type: Gigabit Ethernet CardManufacturer Part Number: H50218Manufacturer Website Address: http://www.hiroinc.comManufacturer: Hiro, IncProduct Model: H50218Product Name: Ethernet PCIe AdapterPackage Type: RetailBrand Name: HiroI/O ExpansionsMedia & PerformanceTwisted Pair Cable Standard: Category 5eMedia Type Supported: Twisted PairMiscellaneousDevice Supported PCPlatform Supported PCCertifications & Standards CE FCC IEEE Standards: 802.3 802.3u 802.3ab 802.3x Green Compliant YesGreen Compliance Certificate/Authority RoHSNetwork & CommunicationNetwork Technology: 10/100/1000Base-TPhysical CharacteristicsThickness: 63.0 milWeight (Approximate): 4.00 ozForm Factor: Plug-in CardHeight: 2.6"Width: 1.6"Card Height: Low-profileWarranty
Technical Specifications
Standards: IEEE 802.3 10Base-T, IEEE802.3u 100Base-TX
Protocol: CSMA/CD
PCI Express Bus PCI Express 1.0a
Transmission Rate: 10/100Mbps for Half-Duplex mode
20/200/2000Mbps for Full-Duplex mode
Port: 1 x 10/100/1000Mbps Auto-Negotiation RJ45 Port
Network Media 10BASE-T: UTP category 3, 4, 5 Cable (maximum 100m)
EIA/TIA-568 100 STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100 STP (maximum 100m)
1000Base-T: UTP category 5, 5e cable (maximum 100m)
LED Indicators: Link/Act
Environment Operating Temperature: 040
Storage Temperature: -4070
Operating Humidity: 10%90% non-condensing
Storage Humidity: 5%95%, non-condensing
Certificate: CE, FCC
Fully Compatible with latest Microsoft Windows OS, -Windows 7 32/64Bit, Vista 32/64Bit, XP 32/64Bit, 2000, Server 2008/2003/2000 32/64Bit, ME, 98SE Item Dimension (L"xW"xH")
6 x 5 x 2
Weight
1.00 lb
Warranty Information
1 Year
