Technical Specifications
CPU
Support for Intel Xeon E3-1200 v5 Processor / Intel Core i3 Processor / Intel Pentium / Intel Celeron Processor in the LGA1151 Package
L3 Cache Caries with CPU Chipset
Intel C232 Chipset Memory
2 x DDR4 DIMM Sockets supporting up the 32GB of System Memory
Dual Channel Memory Architecture
Support for DDR4 2133 MHz Memory Modules
Support for non-ECC UDIMM 1Rx8/2Rx8/1Rx16 Memory Module Audio
Realtek ALC887 Codec
High Definition Audio
2/4/5.1/7.1 Channel
Support for S/PDIF Out LAN
Intel GbE LAN Chip (10/100/1000 Mbit) Expansion Slots
1 x PCI Express x16 Slot, running at x16
2 x PCI Express x1 slot
(All of the PCI Express Slots conform to PCI Express 3.0 Standard) Storage Interface
Chipset:
- 6 x SATA 6Gb/s Connectors
- Support for RAID 0, RAID 1, RAID 5, and RAID 10 USB
Chipset:
- 6 x USB 3.0/2.0 ports (4 ports on the back panel, 2 ports available through the internal USB header)
- 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers) Internal I/O Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
6 x SATA 6Gb/s connectors
1 x CPU fan header
1 x system fan header
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
1 x USB 3.0/2.0 header
2 x USB 2.0/1.1 headers
1 x Trusted Platform Module (TPM) header
1 x serial port header
1 x Clear CMOS jumper Back Panel Connectors
1 x PS/2 keyboard port
1 x PS/2 mouse port
4 x USB 3.0/2.0 ports
2 x USB 2.0/1.1 ports
1 x RJ-45 port
3 x audio jacks (Line In, Line Out, Mic In) I/O Controller
iTE I/O Controller Chip H/W Monitoring
System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU/System overheating warning
CPU/System fan fail warning
CPU/System fan speed control BIOs
1 x 64 Mbit Flash
Use of Licensed AMI UEFI BIOs
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOs 2.7, ACPI 5.0 Unique Features
Support for APP Center
BIOs
Support for Q-Flash
Support for Smart Switch
Support for Xpress Install Bundle Software
Norton Internet Security (OEM Version)
cFosSpeed Operating Support
Support for Windows 10/8.1 64-Bit
Support for Windows 7 32/64-Bit Form Factor
Micro ATX Form Factor Item Dimension (L"xW"xH")
11 x 10 x 3
Weight
2.00 lb
Warranty Information
3 Years
