Technical Specifications
Networking
Compliant Standards:
IEEE 802.1Q , IEEE 802.1x , IEEE 802.3i , IEEE 802.3u
Connectivity Technology:
Wired
Data Link Protocol:
Ethernet , Fast Ethernet
Data Transfer Rate:
1 Gbps
Form Factor (FE):
Desktop
Integrated Switch:
8-port switch
Network Transport Protocol:
DDNS , DHCP , DNS , IPSec , L2TP , PPPoE , PPTP
Remote Management Protocol:
CLI , HTTP , HTTPS , SNMP 1 , SNMP 2c , SNMP 3
Routing Protocol:
Static IP routing
Status Indicators:
Link activity , Port status
Type:
Router
WAN Ports Qty:
1
Miscellaneous
Authentication Method:
RADIUS
Compliant Standards:
C-Tick , cUL , EN 60950-1 , FCC Class B certified , RoHS , VCCI , WEEE
Encryption Algorithm:
AES , Blowfish , CAST-128 , DES , PEAP , SSL , TLS , Triple DES , TTLS , Twofish
MTBF:
240,000 hour(s)
Interface Provided
Connector Type:
RJ-45
Interface:
Ethernet 10Base-T/100Base-TX
Qty:
1
Type (FF):
WAN
Qty:
8
Type (FF):
LAN
Interface:
Console
Type (FF):
Management
Connector Type:
4 pin USB Type A
Type (FF):
Hi-Speed USB
Service
Support Details Full Contract Period:
Lifetime
Support Details Type:
Limited warranty
Header
Compatibility:
PC
Manufacturer:
D-Link
Model:
DSR-150
Packaged Quantity:
1
Product Line:
D-Link Unified Services Router
Power Device
Form Factor:
Internal
Frequency Required:
50/60 Hz
Nominal Voltage:
AC 100/230 V
Power Consumption Operational:
7.44 Watt
Type:
Power supply
Capacity
Type:
PPTP VPN tunnels
Value:
10
Type:
IPSec VPN tunnels
Type:
SSL VPN tunnels
Value:
1
Type:
Firewall policies
Value:
200
Type:
New sessions per second
Type:
Concurrent sessions
Weight
1.88
Item Dimension
11.34 x 9.76 x 2.6
Warranty Information
Limited Lifetime
