Technical Specifications
Compatible Product Series
Intel Xeon Processor E3-1200 v6 Family Board Form Factor
uATX Chassis Form Factor
Pedestal Socket
1 Integrated Systems Available
No Integrated BMC with IPMI
IPMI 2.0 Embedded Options Available
No TDP
80 W Board Chipset
Intel C236 Chipset Memory Specifications
Max Memory Size (dependent on memory type) : 64 GB
Memory Types : DDR4 ECC UDIMM
Max of Memory Channels : 2
Max Memory Bandwidth : 68.256 GB/s
Physical Address Extensions : 40-bit
Max of DIMMs : 4
ECC Memory Supported : Yes
DIMM Type : UDIMM Graphics Specifications
Integrated Graphics : Yes
Graphics Output : Display Port, VGA Expansion Options
PCI Express Revision : 3.0
Max of PCI Express Lanes : 20
PCIe x4 Gen 3 : 1
PCIe x8 Gen 3 : 1
PCIe x16 Gen 3 : 1
Connector for Intel I/O Expansion Module x8 Gen 3 : 1
Connector for Intel Integrated RAID Module : 1 I/O Specifications
USB Revision : 2.0 and 3.0
USB Ports : 9
Total of SATA Ports : 8
RAID Configuration : Software RAID RST (0,1,10,5) and ESRT2 (0,1,10)
Serial Ports : 1
LAN Ports : 2
Integrated LAN : 2x 1GbE
Embedded USB (eUSB) Solid State Drive Option : No
Integrated InfiniBand : No Advanced Technologies
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel Remote Management Module Support : Yes
Intel Node Manager : Yes
Intel Rapid Storage Technology enterprise : Yes
Intel I/O Acceleration Technology : Yes Intel Platform Protection Technology
Trusted Execution Technology : Yes Intel Transparent Supply Chain
TPM Version : 1.2 Item Dimension (L"xW"xH")
16 x 11 x 14 Weight
15.00 lb Warranty Information
Intel 3-year limited
