Technical Specifications
HDMI 1.2 compliant Pixel rate
165MHz (Max) Supports Audio support stereo PCM (48KHz) Input TMDS signal
1.2V (peak-to-peak) Input DDC signal
5V (peak-to-peak, TTL) Supports UXGA (1600 x 1200) and WUXGA (1920 x 1200) PC graphic output Supports HDTV (1080p / 720p) video output ESD protection
+/-19kV Air and +/-12kV Contact Metal housing with wall mount design USB firmware upgrade ability for expanding compatibility Device control
Software control via Micro-USB port
Push button (OSD)
IR remote control (included) Product
Color: Black
Housing: Metal, wall mountable
Connectors:
1x 15-Pin D-Sub (VGA), Female, Input
1x 19-Pin HDMI, Type A, Female, Output
1x 3.5mm, Stereo Audio, Input
1x 5-Pin Micro USB, Firmware upgrade/Software control
1x 2-Pin Dip Switch, Operating mode
Power jack, Power input Power adapter
Input: 100-240VAC, 50/60Hz
Output: DC 5V/2A
UL:E135856 / Class VI Environmental conditions
Operating temperature: 32 to 104 degrees F
Storage temperature: -4 to 140 degrees F
Relative humidity: 20 to 90% RH (non-condensing) Certifications/Standards
FCC, CE, RoHS TAA Compliant Note:
- Does not support HDMI to VGA conversion Item Dimension (L"xW"xH")
8 x 6 x 3
Weight
2 lbs
Warranty Information
3 years
