The Xeon E3 processor family is a great choice entry workstation and entry server solutions, which establish a foundation of capability to support small businesses' growing and changing demands. The Xeon E3 processor family delivers trusted performance and proven innovation that will help you win and stay ahead of the competition. A host of hardware-enhanced security and reliability features help protect your data - the valuable asset for a small business and also the connection to customers, sales, inventory, financial records, and ultimately growth. Position your company for growth with a powerful and affordable small business server based on the Intel Xeon processor E3 family.
Technical Specifications
Essentials Vertical Segment: Server Processor Number: E3-1230V6 Performance number of Cores: 4 number of Threads: 8 Processor Base Frequency: 3.50 GHz Max Turbo Frequency: 3.90 GHz Cache: 8 MB Bus Speed: 8 GT/s DMI3 TDP: 72 W VID Voltage Range: 0.55V-1.52V Supplemental Information Embedded Options Available: No Conflict Free: Yes Memory Specifications Max Memory Size (dependent on memory type): 64 GB Memory Types: DDR4-2400, DDR3-1866 Max number of Memory Channels: 2 Max Memory Bandwidth: 37.5 GB/s ECC Memory Supported: Yes Graphics Specifications Processor Graphics: None Graphics Output: N/A 4K Support: No Max Resolution (HDMI 1.4): N/A Max Resolution (DP): N/A Max Resolution (eDP - Integrated Flat Panel) : N/A Max Resolution (VGA) : N/A DirectX Support: N/A OpenGL Support: N/A Intel Quick Sync Video: No Intel InTru 3D Technology: No Intel Clear Video HD Technology: No Intel Clear Video Technology: No number of Displays Supported: 0 Expansion Options Scalability: 1S Only PCI Express Revision: 3.0 PCI Express Configurations: 1x16, 2x8. 1x8+2x4 Max number of PCI Express Lanes: 16 Package Specifications Sockets Supported: FCLGA1151 Max CPU Configuration: 1 Advanced Technologies Intel Optane Memory Supported: Yes Intel Turbo Boost Technology: 2.0 Intel vPro Technology: Yes Intel Hyper-Threading Technology: Yes Intel Virtualization Technology (VT-x) : Yes Intel Virtualization Technology for Directed I/O (VT-d) : Yes Intel VT-x with Extended Page Tables (EPT): Yes Intel TSX-NI: Yes Intel 64: Yes Instruction Set: 64-bit Instruction Set Extensions: SSE4.1/4.2, AVX 2.0 Idle States: Yes Enhanced Intel SpeedStep Technology: Yes Thermal Monitoring Technologies: Yes Intel Data Protection Technology Intel AES New Instructions: Yes Secure Key: Yes Intel Software Guard Extensions (Intel SGX) : Yes Intel Memory Protection Extensions (Intel MPX) : Yes Intel Platform Protection Technology OS Guard: Yes Trusted Execution Technology: Yes Execute Disable Bit : Yes Intel Device Protection Technology with Boot Guard: Yes Item Dimension (L inchxW inchxH inch) 5 X 4 X 3
Weight 1.00 lb
Warranty Information Intel 3-year limited
Product Details
Manufacturer:
Model Number:
ASIN:
UPC:
Condition:
Weight:
Dimensions:
Updated:
Added:
Intel
BX80677E31230V6
B06XXFBV41
735858328425
New
1 lbs
0 X 0 X 0
Apr 25, 2026
Apr 02, 2017
Product Identifiers:
Brand: Intel •
Part #: BX80677E31230V6 • UPC: 735858328425 • ASIN: B06XXFBV41 • Category: Server CPUs/Processors
