BOXNUC8I7BEKQA1 - Intel I7 NUC 512GB SSD 16GB MEM WIN10

Essentials
Product Collection
Intel NUC Mini PC with 8th Generation Intel Core Processors
Code Name
Products formerly BEAN CANYON
Board Form Factor
UCFF (4" x 4")
Socket
Soldered-down BGA
Internal Drive Form Factor
M.2 SSD
Number of Internal Drives Supported
1
Lithography
14 nm
TDP
28 W
DC Input Voltage Supported
12-19 VDC
Pre-Installed Operating System
Windows 10, 64-bit
Processor Included
Intel Core i7-8559U Processor (8M Cache, up to 4.50 GHz) Supplemental Information
Embedded Options Available
No
Description
Other features: 512GB NVMe SSD and Windows 10, 64-bit Home pre-installed, includes Thunderbolt 3 (40Gbps) USB 3.1 Gen 2 (10Gbps) and DP 1.2 via USB-C also includes microSDXC card slot, dual microphones Memory and Storage
Included Storage
512GB Intel 760p NVMe SSD
Included Memory
2x 8GB DDR4-2400
Max Memory Size (dependent on memory type)
32 GB
Memory Types
DDR4-2400 1.2V SO-DIMM
Max Number of Memory Channels
2
Max Memory Bandwidth
38.4 GB/s
Max Number of DIMMs
2
ECC Memory Supported
No Processor Graphics
Integrated Graphics
Yes
Graphics Output
HDMI 2.0a USB-C (DP1.2)
Number of Displays Supported
3 Expansion Options
PCI Express Revision
Gen3
PCI Express Configurations
M.2 slot with PCIe X4 lanes
Removable Memory Card Slot
microSDXC with UHS-I support
M.2 Card Slot (storage)
22x42/80 I/O Specifications
Number of USB Ports
6
USB Configuration
2x front and 3x rear USB 3.1 Gen2 2x USB 2.0 via internal headers
USB Revision
2.0, 3.1 Gen2
USB 2.0 Configuration (External + Internal)
0 + 2
USB 3.0 Configuration (External + Internal)
2B 2F + 0
Total Number of SATA Ports
2
Max Number of SATA 6.0 Gb/s Ports
2
Audio (back channel + front channel)
7.1 digital (HDMI mDP) L+R mic (F)
Integrated LAN
Intel Ethernet Connection I219-V
Integrated Wireless
Intel Wireless-AC 9560 + Bluetooth 5.0
Integrated Bluetooth
Yes
Consumer Infrared Rx Sensor
Yes
Additional Headers
CEC, 2x USB2.0, FRONT_PANEL
Number of Thunderbolt 3 Ports
1 Advanced Technologies
Intel Optane Memory Supported
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel vPro Platform Eligibility
No
TPM
No
Intel HD Audio Technology
Yes
Intel Rapid Storage Technology
Yes
Intel Virtualization Technology (VT-x)
Yes
Intel Platform Trust Technology (Intel PTT)
Yes Security and Reliability
Intel AES New Instructions
Yes Item Dimension (L"xW"xH")
5 x 1 x 4

Weight
1 lb

Warranty Information
3-year limited
