BKNUC8CCHKR1 - Intel BTO NUC

Essentials
Product Collection
Intel NUC Kit with Intel Celeron Processors
Code Name
Intel NUC 8 Rugged Kit NUC8CCHKR
Status
Launched
Supported Operating Systems
Windows 10, 64-bit
Board Number
NUC8CCHB
Board Form Factor
3.5 SBC (146mm x 101.6mm)
Internal Drive Form Factor
M.2 SSD
Embedded Storage
64 GB
Off Roadmap
No
DC Input Voltage Supported 12V - 24V
Processor Included
Intel Celeron Processor N3350 (2M Cache, up to 2.4 GHz)
Number of Cores
2
Number of Threads
2
Processor Base Frequency
1.10 GHz
Recommended Customer Price
226.00 - 227.70 dollars
Supplemental Information
Embedded Options Available
No
Memory and Storage
Included Storage
64GB eMMC
Included Memory
4GB LPDDR3 (dual-channel, soldered-down)
ECC Memory Supported
No
Processor Graphics
Processor Graphics
Intel HD Graphics 500
Graphics Output
HDMI 2.0, HDMI 1.4, 4-lane eDP 1.4
Number of Displays Supported
2
Expansion Options
PCI Express RevisionGen
2
M.2 Card Slot (wireless)
22x30 slot (key E)
M.2 Card Slot (storage)
22x80 slot (key M, NVMe/SATA)
I/O Specifications
Number of USB Ports
4
USB Configuration
1x front and 1x rear USB 3.0
2x rear USB 2.0
1x USB 3.0 and 2x USB 2.0 via internal headers
Serial Port via Internal Header
Yes
Audio (back channel + front channel)
1/8" line out
Integrated LAN
Intel i211-AT (10/100/1000 Mbps)
Integrated Wireless
Intel Dual Band Wireless-AC 3168
Integrated Bluetooth
Yes
Additional Headers
Front_panel (PWR, RST, 5V, 5Vsby, 3.3Vsby), Internal 2x2 power connector
Advanced Technologies
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
TPM
No
Intel HD Audio Technology
Yes
Intel Virtualization Technology (VT-x)
Yes
Intel Platform Trust Technology (Intel PTT)
Yes
Security and Reliability
Intel AES New Instructions
Yes
Intel Trusted Execution Technology
No
Item Dimension (L"xW"xH")
7 x 5 x 4
Weight
2.70 LB
Warranty Information
3-year limited
