Technical Specifications
GENERAL SPECIFICATIONS:
Cooling Fans
Single, 1350mm chassis Fan Total Power Output
850W TOTAL CONTINUOUS OUTPUT at 40 C Output Connectors
MAIN 24PIN, (8) PCI-E 6+2Pin, (2) 4+4 PIN, (13) SATA,(6) MOLEX 4-PIN, (1) FDD 4-PIN NVIDIA SLI Support
Yes AMD/ATI CrossFire Support
Yes 80 PLUS Certified
Platinum Modular Cable
Yes Safety Approvals
TUV, CE, UL, FCC, BSMI, GOST, C-tick, CCC MTBF
100,000 HOURS at TYPICAL INPUT SPECIFICATIONS:
Input Voltage
100V AC to 240V AC, 47 to 63Hz Power Factor Correction (PFC)
Active PFC / Full Range Input Current10 Amp (maximum) at 100-127Vrms/ 60 Hz
5 Amp (maximum) at 200-240 Vrms/ 50 Hz. Input Protection
Patented Input Fuse Protection OUTPUT SPECIFICATION
+12V Rails
1 Output Voltage
+3.3V DC
+5V DC
+12V DC
-12V DC
+5Vsb DC (Standby) Output Current
25A at +3.3V DC
25A at +5V DC
70A at +12V DC
0.8A at -12V DC
3.0A at +5Vsb DC Standby Output Protection
Complete OCP, OVP, SCP, OPP, UVP, OTP Protection
