Fsp Group AURUM PT-1000FM FSP Power Supply AURUM PT-1000FM 1000 Watts ATX 13.5CM FAN 24Pin SATA APFC 80PLUS Platinum Ret

GENERAL SPECIFICATIONS
COOLING Fan(s): Single, 135mm chassis Fan
TOTAL POWER OUTPUT: 1000W TOTAL CONTINUOUS OUTPUT at 40^oC
OUTPUT CONNECTORS: MAIN 24PIN, (8)PCI-E 6+2Pin, (2)4+4 PIN, (13)SATA,(6)MOLEX 4-PIN, (1)FDD 4-PIN
NVIDIA SLI SUPPORT: YES
AMD/ATI CROSSFIRE SUPPORT: YES
80PLUS CERTIFIED: PLATINUM
MODULAR CABLE: YES
SAFETY APPROVAL: TUV, CE, UL, FCC, BSMI, GOST, C-tick, CCC
MTBF: 100,000 HOURS at TYPICAL INPUT SPECIFICATIONS
Input Voltage: 100V AC to 240V AC, 47 - 63Hz
Power Factor Correction (PFC): ACTIVE PFC FULL RANGE
Input Current: 10 Amp (maximum) at 100-127Vrms/ 60 Hz
5Amp (maximum) at 200-240 Vrms/ 50 Hz.
Input Protection: Patented Input Fuse Protection OUTPUT SPECIFICATIONS
+12V RAILS: 1
Output Voltage: +3.3V DC
+5V DC
+12V DC
-12V DC
+5Vsb DC (Standby)
Output Current: 25A at +3.3V DC
25A at +5V DC
83A at +12V DC
0.8A at -12V DC
3.0A at +5Vsb DC Standby
Output Protection: Complete OCP, OVP, SCP, OPP, UVP, OTP Protection Item Dimension (L"xW"xH")
8 x 6 x 4

Weight
5 lbs

Warranty Information
7 Years
