Technical Specifications
CPU
Build in Intel Socket 2011-3 Processors
Intel Socket 2011-3 for Intel Xeon processor E5-2600 v3 product family
Chipset
Intel C612 PCH Memory
16 x DIMM, Max. 1024GB, DDR4 2133/1866/1600 MHz RDIMM, LR-DIMM, NVDIMM Memory
Quad Channel Memory Architecture Graphic
ASpeed AST2400 32MB
VGA port
- Supports VGA with max. resolution 1920 x 1200 at 60 Hz Multi-GPU Support
Supports NVIDIA 3-Way SLI Technology
Supports AMD Quad-GPU CrossFireX Technology
Expansion Slots
4 x PCIe 3.0/2.0 x16 (x16 mode)
2 x PCIe 3.0/2.0 x16 (x8 mode) Storage
Intel C612 chipset :
10 x SATA 6Gb/s port(s), gray,
1 x M.2 Socket 3, black,
Support Raid 0, 1, 5, 10
LAN
Intel I210-AT, 2 x Gigabit LAN Controller(s)
1 x Management LAN Audio
Realtek ALC1150 8-Channel High Definition Audio CODEC
- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
- High quality 112 dB SNR stereo playback output (Line-out at rear) and 104 dB SNR stereo playback input (Line-in) Audio Feature :- DTS Ultra PC II
- DTS Connect
- Optical S/PDIF out port(s) at back panel
- BD Audio Layer Content Protection
- Absolute Pitch 192khz/24bit true BD lossless sound USB Ports
IntelC612 Chipset : 6 x USB 3.0/2.0 port(s) (4 at back panel, , 2 at mid-board)
IntelC612 Chipset : 6 x USB 2.0/1.1 port(s) (4 at back panel, , 2 at mid-board) Workstation Feature
6 x PCIe x 16 slot(s)
ASWM Enterprise
ASUS Dr. Power
12K hours Capacitors
ProCool Power Connector
Q-Code Logger
USB BIOS Flashback
ASUS PIKE SAS upgrade kit(Optional)
ASMB8-iKVM Remote Management Tool Back I/O Ports
1 x PS/2 keyboard/mouse combo port(s)
2 x LAN (RJ45) port(s)
4 x USB 3.0 (blue)
4 x USB 2.0 6
1 x Optical S/PDIF out
1 x USB BIOS Flashback Button(s)
1 x Q-Code Logger button
1 x 8-channel Audio I/O
1 x Management LAN Internal I/O Ports
1 x AAFP connector
1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s) (19-pin)
1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
1 x M.2 Socket 3
1 x TPM connector(s)
1 x COM port(s) connector(s)
10 x SATA 6Gb/s connector(s)
2 x CPU Fan connector(s) (2 x 4 -pin)
7 x Chassis Fan connector(s) (7 x 4 -pin) 1 x S/PDIF out header(s)
2 x 8-pin EATX 12 V_1 Power connector(s)
1 x 24-pin EATX Power connector(s)
1 x RAID key header(s)
1 x VGA connector(s)
1 x AUX panel header(s)
1 x SMBus header(s)
2 x System panel(s) (Q-Connector) 1 x Chassis Intrusion connector(s)
1 x TPU switch(es)
1 x Power-on button(s)
1 x Reset button(s)
1 x Clear CMOS button(s)
1 x Dr.Power switch(es)
2 x Serial Port header
1 x ASMB8-iKVM connector Accessories
I/O Shield
1 x COM port cable(s)
10 x SATA 6Gb/s cable(s)
1 x Supporting DVD
1 x 3-Way SLI bridge(s)
1 x SLI bridge(s)
1 x 2-port USB 2.0 module(s)
1 x VGA bracket(s)
1 x SCD
1 x ASWM Enterprise SDVD
1 x ASMB8 Support DVD BIOS
128 Mb Flash ROM, UEFI BIOS, PnP, WfM2.0, SMBIOS 2.6.1, ACPI 3.0, ASUS EZ Flash Utility, ASUS CrashFree Technology Manageability
WfM 2.0, DMI 2.0, WOL by PME, PXE
Support Disc
DriversASUS UtilitiesASUS Update Operating System
Windows Server 2012 R2
Windows Server 2012
Windows Server 2008 Enterprise SP2 64-bit
Windows 8.1 64-bit
Windows 8 64-bit
Windows 7 32/64-bit
Form Factor
EEB Form Factor
12 inch x 13 inch ( 30.5 cm x 33.02 cm ) Item Dimension (L"xW"xH"):
16.73 x 15.55 x 3.19
Weight:
6.5 lb
Warranty Information:
3 Years w/ 1st Year ARS
