Special Order
Ships in 1-2 weeks
Condition: New
| Audio Interface | USB 2.0 high-speed/ USB 1.0 for playback |
|---|---|
| Audio Performance | |
| Output Signal-to-Noise Ratio (A-Weighted) (Front-out) | 114 dB |
| Input Signal-to-Noise Ratio (A-Weighted) | 110 dB |
| Output THD+N at 1kHz (Front-out) | >0.0006 %(104 dB) |
| Frequency Response (-3dB, 24bit/96KHz input) | 10 Hz to 46 KHz |
| Line output (RCA, 3.5) | 1 Vrms (2.828 Vp-p) |
| Headphone output | 1.3 Vrms (3.677 Vp-p) |
| Chipset | |
| Audio Processor | C-Media USB2.0 6632AX High-Definition Sound Processor (Max. 192KHz/24bit) |
| Digital-to-analog Converter(DAC) | Cirrus Logic CS4398 |
| Sample Rate and Resolution | |
| Analog Playback Sample Rate and Resolution | 44.1K/48K/88.2K/96K/176.4K/192KHz at 16bit/24bit |
| Analog Recording Sample Rate and Resolution | 44.1K/48K/88.2K/96K/176.4K/192KHz at 16bit/24bit |
| S/PDIF Digital Output | 44.1K/48K/88.2K/96K/176.4K/192KHz at 16bit/24bit |
| Connectivity | Analog Output : |
| Analog Input | 1 x 3.5 mm jack (1/8") (Line-in/ Mic-in combo) |
| Digital | 1 x S/PDIF out (1 x Coaxial) |
| Special Features | Sonic Studio |
| Operating System | Windows 10 |
| Accessories | S/PDIF adapter x 1 |
| Item Dimension (L"xW"xH") | 6 x 4 x 1 |
| Weight | 1.41 lb |
| Warranty Information | 1 Year Warranty |
