X10SLH-F-O - Supermicro LGA1150/ Intel C226 PCH/ DDR3/ SATA3&USB3.0/ V&2GbE/ MicroATX Server Motherboard

Processor/Cache:
CPU:
- Intel Xeon Processor E3-1200 and v3 (Supports VHD via E3-1285 or E3-1285L) and 4th Gen Core i3, Pentium, Celeron Processor
Single Socket H3 (LGA 1150) System Memory:
Memory Capacity:
- 4 x 240-Pin DDR3 DIMM Sockets
- Supports up to 32GB DDR3 ECC/Non-ECC Unbuffered Memory (UDIMM)
Memory Type:
- 1600MHz ECC DDR3 SDRAM 72-bit, 240-pin gold-plated DIMMs
DIMM Sizes:
- 8GB, 4GB, 2GB, 1GB
Memory Voltage:
- 1.5V
Error Detection:
- Correct Single Bit Errors
- Detects Double Bit Errors (Using ECC Memory) Onboard Devices:
Chipset:
- Intel C226 Express PCH
SATA:
SATA3 (6Gbps) with RAID 0, 1, 5, 10
IPMI:
Support for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with Virtual Media Over LAN and KVM-Over-LAN Support
Network Controllers:
- Intel i210AT Controllers
- Virtual Machine Device Queues High efficient I/O overhead
- Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
- 1x Realtek RTL8201N PHY (Dedicated IPMI) Input/Output:
Serial ATA:
- 6x SATA3 (6Gb/s) Ports
LAN:
2 x Gigabit Ethernet LAN Ports
- 1 x RJ45 Dedicated IPMI LAN Port
USB:
- 4 x USB 3.0 Ports (2 Rear, 1 Type-A)
6 x USB 2.0 Ports (2 Rear, 4 Via Header)
VGA:
1 x VGA D-SUB Connector
Serial Port/Header:
2 x COM Ports (1 Rear, 1 Header)
DOM:
SATA DOM (Disk on Module) Power Connector Support
TPM:
- 1 x TPM 1.2 20-Pin Header Expansion Slots:
PCI-Express:
- 1x PCI-E 3.0 x8 (in x16) slot
- 1x PCI-E 3.0 x8 slot
- 1x PCI-E 2.0 x4 (in x8) slot System BIOs:
BIOs Type:
- 128Mb SPI Flash EEPROM with AMI BIOs
BIOs Features:
- DMI (SMBIOS) 2.7
-ACPI 5.0
- USB Keyboard Support Management:
Software:
- IPMI (Intelligent Platform Management Interface) v2.0 with KVM support
- SuperDoctor III
- Watch Dog
- NMI
Power Configuration:
- ACPI/ACPM Power Management
- Main Switch Override Mechanism
- Power-On Mode for AC Power Recovery
Internal/External Modem Ring-On PC Health Monitoring:
Voltage:
- Monitors for CPU Cores, +12V, +3.3V, +5V, +5V Standby, VBAT, HT, Memory, Chipset Voltages
- 5-Phase-switching voltage regulator with auto-sense from 0.8375V-1.60V
Fan:
- Total of five 4-pin fan headers supporting up to 5 fans
- 5x fans with tachometer status monitoring
- Status monitor for speed control
- Status monitor for on/off control
- Support 3-pin fans (w/o speed control)
- Low noise fan speed control
- Pulse Width Modulated (PWM) fan connectors
Temperature:
- Monitoring for CPU and chassis environment
- CPU thermal trip support
- FC temperature sensing logic
- Thermal Monitor 2 (TM2) support
- PECI
LED:
- CPU / System Overheat LED
- +5V Standby Alert LED
Other Features:
Chassis Intrusion Detection
Chassis Intrusion Header Form Factor
uATX Item Dimension (L"xW"xH")
9.6 x 9.6 x 1

Weight
2.00 lb

Warranty Information
1 Year
