Technical Specifications
Form Factor
Flex ATX CPU
Intel Xeon processor D-1518, 2.2GHz, CPU TDP support 35W
FCBGA 1667 Cores / Cache
4 Cores, 8 Threads / 6MB Memory Capacity
4x DDR4 DIMM sockets
Supports up to 128GB DDR4 ECC RDIMM
Supports up to 64GB DDR4 ECC/non-ECC UDIMM Memory Type
2133/1866/1600MHz ECC DDR4 ECC RDIMM and ECC/Non-ECC UDIMM DIMM Sizes
32GB, 16GB, 8GB, 4GB Memory Voltage
1.2 V Error Detection
Corrects single-bit errors
Detects double-bit errors (using ECC memory) Chipset
System on Chip SATA
SoC controller for 4 SATA3 (6Gbps) ports RAID 0,1,5,10 RSTe Network Controllers
Dual 10G SFP+ from D-1500 SoC
Dual 1GbE with Intel I210 IPMI
Support for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support Video
Aspeed AST2400 TPM
TPM 2.0 header Input / Output SATA
4 SATA3 (6Gbps) ports LAN
2 10G SFP+ LAN ports
2 1GbE LAN ports
1 Dedicated IPMI LAN port USB
2 USB 3.0 ports (rear)
5 USB 2.0 ports (4 via headers, 1 Type A) Video
1 VGA port Serial Port / Header
1 COM port (header) DOM
2 SuperDOM (Disk on Module) power connectors
