Technical Specifications
MB Physical Status
Form Factor
CEB
Processor System
CPU
Intel Xeon Scalable Processors (Max 205W) and Intel Xeon W Processor (MAX 255W)
Socket
Single Socket P
Chipset
Intel C621
System Memory
Capacity
8 DIMM slots
Type
- Six Channel Memory Technology
- Support DDR4 2933/2666/2400 RDIMM, LR DIMM and Intel OptaneTM DC Persistent Memory in memory mode
Voltage
1.2V
Expansion Slot
PCIe 3.0 x 16
SLOT1: Gen3 x16 link
SLOT3: Gen3 x16 link, auto switch to x8 link if SLOT2 is occupied
SLOT5: Gen3 x16 link, auto switch to x8 link if SLOT4 is occupied
SLOT7: Gen3 x16 link, auto switch to x8 link if SLOT6 is occupied
PCIE1 is only supported for Intel Xeon W-3200 Processors.
PCIe 3.0 x 8
SLOT2: Gen3 x8 link
SLOT4: Gen3 x8 link
SLOT6: Gen3 x8 link
Storage
SATA Controller
PCH : 10x SATA3 (2x mini-SAS HD, 2x M.2)
Ethernet
Interface
10Gbps/1000Mbps/100Mbps
LAN Controller
- 2 x RJ45 10GbE by Intel X550-AT2
- Supports Wake-On-LAN
- Supports Energy Efficient Ethernet 802.3az
- Supports Dual LAN with Teaming function
- Supports PXE
- LAN1 Supports NCSI
Management
BMC Controller
ASPEED AST2500
IPMI Dedicated GLAN
1 x Realtek RTL8211E for dedicated management GLAN
Features
NMI
Graphics
Controller
ASPEED AST2500
VRAM
DDR4 256MB
Audio
Audio Codec
Realtek ALC892
Rear Panel I/O
PS/2 KB/Mouse
1
VGA Port
1 x D-Sub
USB 3.1 Gen1 Port
3
USB 3.1 Gen2 Port
1 (type C)
Lan Port
- 2 x RJ45: 2x 10GbE by Intel X550-AT2
- 1x IPMI dedicated LAN"
- LAN Ports with LED (ACT/LINK LED and SPEED LED)
UID Button/UID LED
1
Audio
1 (5+1 jack)
Internal Connector
COM Header
1 M.2
2 (up to 22110) Auxiliary Panel Header
1 (includes chassis intrusion, location button and LED, front LAN LED) TR1 Header
1 TPM Header
1 IPMB Header
1 Fan Header
6 x System Fans ATX Power
1 (24-pin) + 3 (8-pin) USB 3.1 (Gen1) Header
2 (support 4 USB 3.1 Gen1 ports)
