Condition: New
Construction: 18 AWG, 7 strand bare copper, 4 conductors twisted and jacketed.
Insulation: SR-PVC.
Color Code: Black, Red, White, Green.
Shield/Drain: Unshielded.
Assembly: 4 conductors twisted and jacketed.
Jacket: PVC.
Diameter: 0.182 Nominal.
UL Rating: CMR or CL3R or FPLR; For plenum rated version, see spec. No. P40031.
Capacitance: 25.4 pF/ft Nom.
Velocity of Propagation: 55%.
Impedance: 73 Ohms.
Resistance: 6.92 Ohms D.C. per 1000 ft @ 68 deg. F maximum.
Temperature/Voltage: 75C / 300V (up to 300V; power-limited systems per NEC Art. 725 or 800).
The Wavenet 18 AWG 4-Conductor Speaker Wire, part number WAV-CC1804URGY4, is designed for signal transmission in commercial and residential audio installations. This unshielded gray wire features four 18 AWG conductors, each composed of 7 strands of bare copper, twisted and jacketed with PVC. It is suitable for power-limited systems up to 300V, as defined by NEC Art. 725 or 800. The wire's construction supports applications requiring CMR, CL3R, or FPLR ratings, indicating its suitability for riser applications. With a nominal diameter of 0.182 inches, it offers a balance of durability and installation flexibility. This product is intended for IT professionals and system integrators who require a reliable, UL-compliant multi-conductor wire for speaker connections and similar low-voltage signaling tasks.
The individual conductors are color-coded black, red, white, and green for easy identification during installation.
This wire is rated for a maximum temperature of 75C and a maximum voltage of 300V, suitable for power-limited systems.
No, this speaker wire is unshielded, which can offer flexibility in certain installation scenarios.
This wire complies with UL ratings CMR, CL3R, or FPLR, indicating its suitability for riser applications.
WAV-CC1804URGY4 - Wavenet 18 AWG 4-Conductor Speaker Wire - Gray
