Technical Specifications
Image Sensor
1/3inch 3Megapixel progressive scan CMOS
Effective Pixels
2048(H)x1536(V)
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1/3(4)1/10000s
Min. Illumination
0. 01Lux/F1.4 (Color), 0Lux/F1.4(IR on)
S/N Ratio
More than 50dB
Video Output
N/A
Max. IR LEDs Length
30m
Day/Night
Auto(ICR)/Color/B/W
Backlight Compensation
BLC / HLC / DWDR
White Balance
Auto/Manual
Gain Control
Auto/Manual
Noise Reduction
3D
Privacy Masking
Up to 4 areas
Focal Length
2.7mm12mm
Max Aperture
F1.4
Focus Control
Auto
Angle of View
H: 92 28
Lens Type
Motorized/ Fixed Iris
Mount Type
Board-in Type
Compression
H.264/ H.264H/ MJPEG
Resolution
3M(2048x1536)/1080P(1920x1080)/1.3M(1280960)/720P(12807 20)/D1(704576/704480)/CIF(352288/352240)
Frame RateMain Stream3M(1 20fps)/1080P (1 25/30fps)
Sub StreamD1/CIF(1 25/30fps)
Bit Rate
H.264H: 40K 8192Kbps MJPEG: 40K16384Kbps
Compression
N/A
Interface
N/A
Ethernet
RJ-45 (10/100Base-T)
Wi-Fi
N/A
Protocol
IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour
Compatibility
ONVIF, CGI, PSIA
Max. User Access
20 users
Smart Phone
iPhone, iPad, Android, Windows Phone
Memory Slot
N/A
RS485
N/A
Alarm
N/A
PIR Sensor Range
N/A
Item Dimension (LxWxH)
7 x 7 x 6.5
weight
0.55 lb
Warranty Infotmation
1 Year
