Technical Specifications
Hardware Specifications
10/100/1000 Mbps RJ-45 Ports: 1 x WAN, 1 x SFP, 4 x LAN/DMZ
USB Ports: 1
Console Port: Yes (RJ-45) System Capacity and Performance
SPI Firewall Throughput: 350 Mbps
VPN Throughput: 90 Mbps
Max TCP Concurrent Session: 20,000
Max Concurrent IPSec VPN Tunnels: 10
Max Concurrent SSL VPN Users: 15
Included SSL VPN User No. 5
Customizable Zones: Yes
IPv6 Support: Yes Key Software Features
Firewall: Yes
Virtual Private Network (VPN): Yes (IPSec, SSL, L2TP Over IPSec)
Anti-Spam: Subscription Based
Content Filtering (CF): Subscription Based
Bandwidth Management: Yes
Logging and Monitoring: Yes
Unified Security Policy: Yes
System Management: Yes Power Requirement
Power Input: 12V DC, 2.0A Max
Max Power Consumption: 12.00W
Heat Dissipation: 40.92 BTU/hr Accessories
Power Adapter
RJ45 - RS232 Cable for Console Connection Environmental Specifications
Operating:
- Temperature: 0 C to 40 C (32 F to 104 F)
- Humidity: 10% to 90% (Non-Condensing)
Storage:
- Temperature: -30 C to 70 C (-22 F to 158 F)
Humidity: 10% to 90% (Non-Condensing)
MTBF: 44,000.00hr Certifications
EMC: FCC Part 15 (Class B), IC, CE, EMC (Class B), RCM, BSMI
Safety
BSMI, UL Item Dimension (L"xW"xH")
9 x 6 x 1
Weight
2.30 lb
Warranty Information
1 Year
