Technical Specifications
OVERVIEW
Technology:
Cat5 / 5e
Cat6
HDMI (All types)
USB (all versions)
USB 3.1 (Gen 1)
INPUT
Bus Powered:Yes
Product Length (ft.):1
USER INTERFACE, ALERTS and CONTROLS
LED Indicators:White (Power), Green (Link), Yellow (Activity) PHYSICAL
Unit Packaging Type:Box
Material of Construction:Aluminium
Color: Gray,Silver
Cable Jacket Rating:VW-1
ENVIRONMENTAL
Operating Temperature Range:32 to 131 oF (0 to 55 oC)
Storage Temperature Range:14 to 158 oF (-10 to 70 oC)
Relative Humidity:5% to 95% RH, Non-Condensing
BTUs: 8.5 BTU/Hr
Power Consumption (Watts):2.5
Power Provided to Connected Device(s):5V 0.9A (4.5W) Output (USB A)
COMMUNICATIONS
Network Speed:1Gbps
IEEE Standards Supported:802.3
CONNECTIONS
Ports: 4
Side A - Connector 1: (1) USB C (MALE)
Side B - Connector 1:
HDMI (FEMALE)
RJ45 (FEMALE)
USB 3.0 A (FEMALE)
USB C (FEMALE)
Connector Plating:Nickel
FEATURES and SPECIFICATIONS
Max Supported Video Resolution: 4K x 2K (3840 x 2160) at 30Hz
HDMI Specification: 2.0
HDCP Specification: 2.2
USB Specification:
USB 3.0 Gen 1 (up to 5 Gbps)
USB 3.1 Gen 1 (up to 5 Gbps)
Driver Required:No
Recommended Category Cable:Cat5 / 5e / 6 Cables
Auto MDIX Support:Yes
Full Duplex Support:Yes
Suspend Mode Support:Yes
Remote Wakeup Support:Yes
CERTIFICATIONS
Certifications:
Tested to CE
FCC
RoHS
REACH Item Dimension (L"xW"xH")
1 x 6 x 4
Weigt
1.00 LB
Warranty Information
3-year limited warranty
