Technical Specifications
Model No.
SST-TX300 Max. DC Output
300W Power density
310W per liter Color
Black(Lead-Free Paint) Combined +3.3V and +5V
95W Combined +12V
276W Input Voltage
90 - 264 Vrms Input Frequency Range
47Hz - 63Hz PFC
Active PFC (PF>0.9 at full load) Efficiency
82% - 85% at 20% - 100% loading MTBF
100,000 hours Operating temperature
0oC - 40oC Protection
Over power protection
Over voltage protection
Short circuit protection Connectors
1 x 24 / 20-Pin motherboard connector (350mm)
1 x 8 / 4-Pin EPS / ATX 12V connector (450mm)
1 x 6-Pin PCIE connector (350mm)
4 x SATA connector ("350mm / 150mm" x 2)
2 x 4-Pin Peripheral connector (350mm / 150mm)
1 x 4-Pin Floppy adapter connector (350mm / 150mm / 150mm) Cooling System
Single 80mm silent fan Form factor
TFX Noise Level
18 dBA minimum Certification
80 PLUS Bronze Other
GPU Support list
Compatible with ATX12V v2.4 Item Dimension (L"xW"xH")
18 x 11 x 10
Weight
26 lbs
Warranty Information
3 Years parts and labor
