Technical Specifications
CPU
Intel Core i5-7500 Quad-core 3.4 GHz (Max. 3.8 GHz) Graphic Processors
9th Intel HD Graphics System Memory
16GB DDR4 (8GB x 2) Total DIMM slots
4 (Max. 64GB) Flash Memory
512MB DOM ODD Expansion Slot
1 x 5.25 5.25" disc burner or 2 x Slim SATA disc burners
( ODD skus come with preloaded Blu-ray ODD ) Preloaded ODD
LG WH16NS58D M.2 Slot
2 x M.2 2242/2260/2280/22110 SATA 6Gb/s SSD
(M.2 SSD is not included) Hard Drive Tray
8 x 2.5/3.5 SATA 6Gb/s, 3Gb/s HDD or SSD Thunderbolt Port
4 x Thunderbolt 3 high-speed port USB Port
1 x USB 3.0 port (Front)
4 x USB 3.0 port (Rear) LAN Port
4 x GbE RJ45 HDMI Output
3 (HDMI 1.4b) PCIe Slot
3 (HDD area: 1 PCIe Gen3 x8, Processor area: 2 PCIe Gen3 x4)
Note: 2 PCIe Gen3 x4 are preinstalled two dual port Thunderbolt 3 AIC Audio Input
Audio In: 2 x 6.3mm MIC In Audio Output
2 x built-in speakers and 1 x 3.5mm Line Out Sound Level (dB)
Sound pressure (LpAm) (bystander position): 21.6 dB
(with 8 x Seagate ST2000VN000-1HJ164 Hard Drive installed) Power Supply
ATX 100-240V, 3-1.5A Output 250W Fan
System Area: 3 x 8 cm cooling Fan
Processor Area: 1 x 9 cm Fan Item Dimension (L inchxW inchxH inch)
20 x 18 x 16
