Technical Specifications
CPU
Intel CoreTM i3-8100T 4-core 3.1 GHz processor
Architecture: 64-bit
Graphics: Intel UHD Graphics 630 Encryption Acceleration
(AES-NI) System Memory
8 GB SODIMM DDR4 (2 x 4 GB) Maximum Memory
32 GB ( 2 x 16 GB) Memory Slot
2 x SO-DIMM DDR4
(For dual- or quad-DIMM configurations, you must use a pair of identical DDR4 modules.) Flash Memory
4 GB (Dual boot OS protection) Drive Bay
Hot-swappable 6 x 3.5-inch SATA 6 Gbps bays Drive Bay
Hot-swappable 6 x 3.5-inch SATA 6 Gbps bays M.2 SSD Slot
2 x M.2 2280 PCIe (Gen3 x2) NVMe slots Thunderbolt Port
2 x ThunderboltTM 3 ports 10 Gigabit Ethernet Port
1 x 10GBASE-T RJ45, supporting 10G/5G/2.5G/1G/100M
Note: Please use CAT6a or CAT 7 LAN cables (sold separately) to achieve 10GbE speed Gigabit Ethernet Port
2 x RJ45 PCIe Slot
Slot 1: PCIe Gen3 x16 (CPU)
Slot 2: PCIe Gen3 x4 (PCH)
Note: Slot 1 is pre-installed with a Thunderbolt 3 adapter USB Port
1 x USB 3.0
2 x Type-C USB 3.1 Gen2 5V/3A 10Gbps
2 x Type-A USB 3.1 Gen2 5V/1A 10Gbps HDMI Output
1 x HDMI 2.0, up to 3840 x 2160, at 60Hz Audio
1 x 3.5 mm dynamic microphone jack
1 x 3.5 mm line-out jack
1 x speaker
Note: You cannot use the speakers and the line-out jack simultaneously. IR sensor
Yes, supports QNAP RM-IR004 remote control LED Indicators
HDD 1-6, Status, LAN, USB port, M.2 port Buttons
Power, Reset, USB One-touch-copy Form Factor
Tower
