Condition: New
16 Gigabit Ethernet ports deliver up to 2000 Mbps of dedicated, non-blocking bandwidth per port
The TPLINK TL-SG1016PE is a 16-port Gigabit Easy Smart Switch designed for businesses expanding their wired network infrastructure. It features 16 10/100/1000Mbps RJ45 ports, providing up to 2000 Mbps of dedicated, non-blocking bandwidth per port. Eight of these ports support PoE+ (Power over Ethernet Plus) and are capable of transferring both data and power over a single Ethernet cable. This switch works with IEEE 802.3af/at compliant devices, making it suitable for powering equipment such as wireless access points, IP cameras, and IP phones without requiring separate power outlets. With a total PoE power budget of 150 W, delivering up to 30 W per port, it addresses the need for flexible device placement. The TL-SG1016PE includes a priority function to manage power distribution during overload scenarios, protecting the system by cutting power to lower-priority ports if total consumption exceeds 150 W. Configuration is simplified through a web-based user interface and management utility, offering a practical solution for network expansion.
The TL-SG1016PE is an 16-Port Gigabit Desktop/Rack mountable Switch with 8 ports supporting the PoE+ standard. It provides a simple way to expand a wired network by transferring power and data over a single Ethernet Cable. With a total power budget of 150 W*, up to 30 W per port, TL-SG1016PE powers more high-powered devices such as wireless Access Points (APs), IP Cameras or IP Phones. Moreover, with innovative energy-efficient technology, the TL-SG1016PE saves the power consumption, making it an eco-friendly solution for your business network.
8 ports of TL-SG1016PE support Power over Ethernet Plus (PoE+) standard which can automatically detect and supply power to any IEEE 802.3af/at compliant device(s). In this situation, the electrical power is transmitted along with data in a single cable, allowing you to expand your network where there are electrical cables or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones.
Overload Arrangement
TL-SG1016PE has a priority function which helps protect the system when its power is overloaded. If all PoE+ devices power consumption is greater than or equal to 150 W, a priority will be arranged among the 8 PoE+ ports, at which point the system will cut off the power of the lowest-priority port.
Port Priority Function
Priority (port 1>port 2>port 3>port 4> port 5>port 6>port 7>port 8): This function will help protect the system if the system power becomes overloaded. For example, Port 1, 2, 3, 4, and 6 are using 30 W (maximum power per port is 30 W), the system power is 150 W in total (PoE max LED will be green if all PoE PDs power consumption. If there is an additional PD inserted to Port 5 with 20 W then the system will cut off Port 6 to protect the system, this means Port 1, 2 ,3, and 4 will use 120 W, and Port 5 will use 20 W, and no power will be supplied to Port 6.
Easy To Use
TL-SG1016PE is easy to install and use. It requires no configuration or installation. With its Desktop/Rack mountable design, outstanding performance and quality, the TP-LINK TL-SG1016PE 16-Port Gigabit Desktop/Rack mountable Switch with 8-Port PoE+ is a great choice for expanding your home or office network.
The TL-SG1016PE has a total PoE power budget of 150 W, with each of the 8 PoE+ ports capable of delivering up to 30 W.
The PoE+ ports are compatible with IEEE 802.3af/at compliant devices, such as wireless Access Points (APs), IP Cameras, and IP Phones.
No, the TL-SG1016PE is designed for simple network setup with plug-and-play connectivity. It also offers a web-based user interface and management utility for simplified configuration.
If the total power consumption of all PoE+ devices exceeds or equals 150 W, the switch will prioritize power delivery based on port number (Port 1 > Port 2 > ... > Port 8). The system will cut off power to the lowest-priority port to protect the system from overload.
TL-SG1016PE - Tplink 16-PORT GIGABIT EASY SMART SWITCH WITH 8-PORT POE+ - RACK-MOUNTABLE - IEEE 802.3
