Technical Specifications
HARDWARE FEATURES
Standards and Protocols
IEEE802.3, 802.3u, 802.3x, CSMA/CD, TCP/IP Interface
24 10/100Mbps Auto-Negotiation RJ45 ports (Auto MDI/MDIX) Network Media
10Base-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100 STP (maximum 100m)
100Base-Tx: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100 STP (maximum 100m) Backup Bandwidth
4.8Gbps External Power Supply
100-240VAC, 50/60Hz LED Indicator
Power, Link/Act, 100Mbps SOFTWARE FEATURES
Basic Function
Wire-speed Performance
MAC Address Auto-Learning and Auto-aging
IEEE802.3x flow control for Full-Duplex Mode and backpressure for Half-Duplex Mode Port Forwarding
10BASE-T: 14880pps/port
100BASE-TX: 148800pps/port Transfer Method
Store-and-Forward MAC Address Table
8k Item Dimension (L"xW"xH")
20.48 x 16.54 x 13.59 Weight
27.73 Warranty
1 Year
