Out of Stock
Condition: New
Product Name
DL2.5
Resolution (Per LED Display Module)
160x120
Pixel Density (Pixels Per LED Display Module)
19,200
Gap Between LED Display Modules
Seamless
LED Type
Commercial Grade 3-in-1 Black SMD
Pixel Configuration
SMD 3-in-1 (1R1G1B)
LED Configuration
1 Red, 1 Green, 1 Blue
LED Surround
Planar MicroGrid Shader Black
Colors
16.7 Million
Color Temperature Adjustable
3200-9300K Adjustable
Color Processing
16 Bits
Contrast Ratio
5000:1 Adjustable
Frame Rate
50/60 Hz
LED Refresh Rate
6300 Hz
Lifetime Typical
100,000 hours to half brightness
Acoustic Noise
Fanless Operation
Operating Temperature/Humidity
14 F to 104 F / -10 C to +40 C, 10-80%
Storage Temperature/Humidity
-4 F to 140 F / -20 C to +60 C, 10-85%
Adjustable MountPlanar Easy Align Mounting System Included
IR Rating
IP40
LED Display Module Alignment/Adjustment
6-Axis Integrated
Standard Mounting Configurations>
Fixed Wall
Optional Mounting Configurations
Floor
Hanging from Truss
Concave
Curved via Third Parties
Regulation Compliance
NRTL, FCC Class A, CE Class A, WEEE, RCM, PSE, REACH, EN60950 and CISPER22/2010, RoHS
Power Supply Type
1U Rack Mount Controller
Redundancy
n+1 Redundant Power Supplies (optional)
Line Voltage
100-240 Volts AC, 50/60Hz auto switching
Power Status
Diagnostic LEDs
Maximum Distance from LED Display Module
200 feet/60 meters (max backlight)
Video Input Type
HDMI v1.4 with HDCP Compliance
Video Input Resolution Maximum
1920x1080 at 50/60 Hz
Video Signal Extension Options
CAT6 (HDBaseT), Fiber Optic
Maximum Distance for LED Video Interface
HDBaseT 326 feet/100 meters, Multimode fiber 984 feet/300 meters
Video Signal Redundancy
Optional
Video Extension Redundancy<>br>Optional
Display Controls
Planar DirectLight Control Software Included
Control Input Type
RS232 or Ethernet
Item Dimension (L"xW"xH")
3 x 16 x 12
Weight
15.80 lb
Warranty Information
3 Years
Planar 997-8121-00 THE DIRECTLIGHT LED VIDEO WALL SYSTEM IS A FAMILY OF SEAMLESS, ULTRA-FINE
